1/2-Inch Copper Electromagnetic Solenoid Valve Industrial Accessory for 12V DC Solar Water Heaters --
You may also like
Compare with similar items
Product information
Description
1. When the supply voltage is 0.9 to 1.1 times the nominal voltage, the solenoid valve can open and close normally within the solenoid valve's water pressure range. 2. The solenoid valve is under the action of an inlet water pressure of 0.02 MPa for 30 seconds and the leak is less than 0.1 ml; when it is under the action of a static water pressure of 0.02 MPa to 0.8 MPa, there is no leak. 3. The solenoid valve is open for 3 seconds and closed for 3 seconds under the action of 1.1 times the nominal voltage when the water pressure is 0.8 MPa, and this cycle lasts 7 × 24 hours (approximately 0.1 billion times) without any anomaly. 4. D Equipped with practical adoptability, the high-quality solenoid valve can maintain high performance for a long period. 5. The solenoid valve is built according to strict quality control standards, improved for greater durability. Technical Specifications: Item Type: Solenoid Valve; Technical Specifications: Pilot Type; Operating Current: 0.46A (DC12V) / 0.24A (DC24V) / 27mA (AC220V)
Power: 5.2W (DC12V) / 5.6W (DC24V) / 5.6W (AC220V)
Operating Temperature Range: 0～80℃
Operating Pressure Range: 0.02～0.8MPa (instantaneously withstands a maximum pressure of 1.75MPa)
Boiler Resistance: 26Ω (DC12V) / 100Ω (DC24V)
Storage Temperature: -20～+80℃ (non-frosting)
Storage Humidity: 25%～95%RH
Package List
1 x Solenoid Valve
Features
- BrandSNQ
- ColourMulticolour
- Height6 cm
- Width10 cm
- Length13 cm
- MaterialCopper
- Weight210 g
- Pcs per pack1
- Voltage12 V
- ManoMano ReferenceME93201197
- MMID624654221360
- Product codeFD-22894
- EAN6032223877866
