1/4" torque wrench, fully adjustable torque wrench with ratchet head (5–25 Nm), 46-piece hand tool set, small set of interchangeable wrenches, ratchet case

Product information

Description

General Description

Fully adjustable 1/4" torque wrench with a torque range of 5 to 25 Nm. Made of chrome vanadium steel, it offers robustness and durability. This kit also includes a 46-piece hand tool set, ideal for small vehicles and bicycles.

Technical Specifications

Type: 1/4" Torque Wrench
Measuring Range: 5–25 Nm
Material: Chrome Vanadium Steel
Drive: 1/4" (6.35 mm)
Maximum Socket Diameter: 14 mm
Reversible ratchet with screw lock
Handle Length: 150 mm
Extensions: 150 mm, 100 mm, 50 mm mm
Sockets: 13 hex sockets (4 to 14 mm)
Hex nuts: 6 (H 3 to 8 mm)
Torx sockets: 6 (T 10 to 40)
Open-end sockets: 3 (4 to 7 mm)
Phillips nuts: 6 (sizes 1 to 3)
Hex keys: 3 (H 1 to 3 mm)

Operation

1. Press and hold the locking button to unlock the wrench.
2. Turn the handle while holding the locking button to set the torque.
3. Release the button to lock the handle after setting the required torque.
4. Check by turning the handle that the wrench is locked.
5. Turn the key clockwise until you hear a click, indicating that the required force has been reached.
6. Reset the key to zero after use. This will prolong its lifespan.

Features

Brand
COOCHEER
Width
10 cm
Material
Steel
Handle material
Steel
Wrench type
Torx key
