180K AC Gear Motor Electric Motor CW/CCW Variable Speed Controller 220V 120W

~~£159.99~~

£1Offered

To be applied on the payment page

Offer valid today only.

Sold by DENCRESTUK

Product information

Description

General description

This gear reducer motor with a speed controller is a highly efficient motor control mechanism that enables precise control of motor speed with high-speed stability and dynamic response. It allows you to adjust the speed according to different loads, achieving the ideal power factor and efficiency, making it suitable for a wide range of industrial applications and various machines.

Technical specifications

Material: Aluminum Alloy, 40cr Alloy Steel

Process: Thermal Refining, Fine Finish, Nitrogen Treatment

Reduction Ratio: 1:180 (180K)

Speed Controller Speed: 0-90 r/min

Motor Speed: 50Hz 90-1350 r/min, 60Hz 90-1650 r/min

Torque: About 3.8 Nm

Power: 120 W

Voltage: 220 V

Motor Type: Gear Motor

Protection Class: IP54

Noise: Around 60 dB

Base Width: 90 mm / 3.54 in

Motor Height: 164 mm / 6.46 in

Reducer Height: 61 mm / 2.4 in

Mounting Hole Distance: 74 mm / 2.91 in

Disk Size (D*H): 34*4 mm / 1.34*0.16 in

Shaft Thickness: 12 mm / 0.47 in

Shaft Height: 29 mm / 1.14 in

Gross Weight: 5.31 kg / 11.7 lbs

Net Weight: 4.56 kg / 10.05 lbs

Package Size: 28.5*24.5*12.5 cm / 11.25*9.65*5.12 in

Installation

The product structure is simple, allowing for quick assembly and use, saving time and labor.

Please connect each wire correctly to ensure that the machine operates normally.

Usage

Ideal for various industries such as packaging, printing, food, textile, and engineering machinery.

Suitable for different machines and production lines including CNC equipment, mechanical equipment, grinding machines, milling machines, printing machines, production workshops, and assembly lines.

Other information

Package includes: 1 Gear Motor, 1 Reducer, 1 Speed Controller.

Notes: Please check the size carefully before ordering. Our motors do not include power cords; you need to purchase a power cord to connect.

Allow for slight color differences caused by lighting and 1-3 cm error due to manual measurement.

Features

Brand
CNCEST
Length
90 mm
Width
74 mm
Weight
4.6 kg
Power
120 W
