1pc Thermostat Socket, Temperature Controller, Programmable Digital Timer with Probe, Thermostat Socket Heating Greenhouse, Aquarium

Intelligent Temperature Controller: Temperature control range: 20℃-60℃, temperature control accuracy: ±1%. The temperature control socket can automatically switch heating and cooling modes by setting the start and stop temperature device to control heating/cooling during the working process.

Multi-function: The LCD screen can display the temperature control mode. It also features temperature correction, screen lock protection and storage (saves all current settings after power failure).

Intelligent Time Control: This thermostatic socket can detect temperature, set switch temperature, and has cycle time control, power on, power off and timer functions. Time range: Range: 0-99 hours 59 minutes,

Time accuracy: up to 10 minutes. Working voltage 250 (V); 1.8m temperature probe: The temperature monitoring socket comes with a 1.8m cable temperature probe to connect to the measuring point. The temperature detection range is 20℃-60℃.

Multiple uses: The digital temperature monitoring socket can intelligently control temperature and time. Widely used in greenhouses, aquariums, carbon crystal heaters, thermostatic switches, portable air conditioners and intelligent controls, etc. Aquaculture, for example, to heat the walls of houses.

Product details

Control method Intelligent temperature controller

Measure the temperature of an object

Temperature range -40-120 (℃)

Temperature measurement error ±0.1 (℃)

Opening size 1 (mm)

Installation type 1

Output signal 1 (mA)

Packing list: Thermostat*1

Product description

Real-time temperature range: -40-120°C.

Open circuit (or below -45℃). The first line of the display flashes "E1" and displays -40~45℃-40℃.

Short circuit (or over 120℃) The first line of the display flashes "E2", 121~129℃ displays 120℃

Niediger is at -10℃ or over 100℃. The values ​​after the decimal point are not displayed.

In cooling mode, when the set temperature is higher than the stop temperature, the corresponding symbol will be displayed.

Heating mode, when the set start temperature is lower than the stop temperature, the heating mode will be displayed on the corresponding symbol.

Mode button:

Press the MODE button, the LCD displays: temperature control mode-timer control mode F01~F04.

F01: Cycle timing mode, cycle timing start time(NO)/stop time(OFF).

F02: Countdown mode, now Ti.s OFF, delay (start time) ON.

F03: Countdown mode is off. At this time, Ti.s is turned on, the delay (stop time) is turned off, the countdown is completed, the output is turned off, and the operation ends.

F04: Countdown mode is turned off, now Ti.s is turned off, the delay (start time) is turned on, the delay (stop time) is turned off after starting, the stop time ends the countdown, turns off the output, and ends the process.

Digital temperature control socket features:

Timer function

Loop time and countdown

heating/cooling

temperature correction

Screen lock function

Memory function: save all current settings after power failure

reset
