Digital Electricity Meter 220V 5(80)A Single Phase DIN Rail Digital Energy Meter 2 Wire 2P DIN Rail Electricity Meter Electronic KWh Meter 1pc

Model DDM15SD

Accuracy: Class 1

Reference voltage: 220V/230V 50/60Hz

Current specification: 5(80)A</ p >

Specify the current specification: reference current (maximum current)

Insulation performance: AC voltage 4KV, 1 minute,

D-shape pulse voltage wave 1.2/50us 6KV

Display mode: LCD with backlight

Installation method: rail installation

Wiring method: low and high / up and down

Product power: 17,000 watts

Ambient temperature: -20℃~+50℃

Note: There is no reset function in this section

< p>Application

DDM15SD single-phase electronic DIN rail active energy meter is a new type of single-phase two-wire active energy meter. It uses microelectronic technology, introduces large-scale integrated circuits, adopts advanced digital technology and SMT technology, etc., and has completely independent intellectual property rights and minimal volume.

< p>The meter fully conforms to the relevant technical requirements for Class 1 single-phase active energy meters in the international standard IEC 62053-21. It can accurately and directly measure active power consumption at 50Hz or 60Hz in single-phase AC network.

It features good reliability, small size, high light weight, beautiful appearance and easy installation.

Features and specifications

Mounting on a standard 35mm DIN rail, according to DIN EN50022 standard.

Bipolar width (17.5mm module), conforms to DIN43880 standard.

Standard configuration 5+1 backlit LCD screen (99999.1kWh).

p>

Function: display of current, voltage, power, frequency, power factor.

The LED provides the signal (red) for the energy pulse.

Unidirectional measurement of single-phase, two-wire active power consumption. It has nothing to do with the charging current flow. Conforms to GB/T17245.321-2008.

For direct connection operation, two wiring methods can be selected. Standard configuration with S-type wiring, optional U-type wiring.

DD15SD series: direct connection, high and low input and output, high and low input and output, installable, S-type wiring with standard configuration.

DDM15SD series: integrated end cover, beautiful and stylish, protect the safety of power consumption.
