Product information

Description

General description

This 4G Home Alarm System Kit is a comprehensive 24-piece smart WiFi wireless home security solution designed to keep your family safe. It combines advanced technology with user-friendly features, providing powerful alarm capabilities and seamless connectivity through the TYAPP app for remote control.

Technical specifications

Input voltage: DC5V (powered by standard USB Type-C interface)

Operating current: <120mA

Alarm current: <650mA

RF wireless: center frequency 433.92MHz, modulation mode ASK, oscillation impedance 330K

Decoding format: 1527/2262 reception support

GSM standard: 4G

WiFi standard: IEEE802.11b/g/n wireless

Operating temperature: -10℃~55℃

Relative humidity: <80% (non-condensing)

Alarm panel battery: 3.7V, 1000mAh (included)

IR detector battery: 2 x AAA 800mAh batteries (included)

Door/window detector battery: 3V, CR2450, 120mAh button cell (included)

SOS button cell battery: 3V, CR2032, 120mAh button cell (included)

Remote control battery: 3V, CR2025, 120mAh button cell (included)

Alarm panel weight: 231g/8.1oz

Alarm panel size: 18.5*12.5*1.5cm/7.3*4.9*0.6inch

Wired alarm size: 5.4*4.8cm/2.1*1.9inch

Infrared detector size: 10.5*4*2.6cm/4.1*1.6*1inch

Door/window sensor size: 6*2.4*1.3cm/2.4*0.9*0.5inch

SOS button size: 5*1.5cm/2.5*0.6inch

Remote control size: 5.7*3.2*1cm/2.2*1.3*0.4inch

Compatibility and accessories

Compatible with Amazon Alexa for voice control

Includes motion detectors, door and window sensors, and a panic alarm distress button

Installation

Designed for easy installation with a user-friendly interface

Usage

Customizable settings to suit individual security preferences

Multilingual support for ease of use by all family members

Features

Brand
SNQ
Power source
Batteries
Remote operation
Yes
Smart
Yes
Colour
Black

4G Home Alarm System Kit, 24 Pieces, Smart WiFi Wireless Home Alarm with App, Motion Detector, Remote Controls, Window and Door Sensors, Siren, Alexa Compatible
