4KW Frequency Inverter VFD Transformer 220V to 380V Speed Controller for Motor, Single-Phase Input 220V, Three-Phase Output 380V, CNC Frequency Converter ZHB600-4KW with 2M Extension Cable
Sold by HYPERDROP
You may also like
Compare with similar items
Product information
Description
【Main Parameters】: Frequency converter input voltage: single-phase 220V; output voltage: three-phase 380V; rated power: 4kW; input frequency: 50 Hz; output frequency: 0-600 Hz; output current: 6.5A.
【Stable Performance】: The frequency converter adjusts the motor's power to allow for variable speed operation while reducing voltage fluctuations in the power lines. Thanks to its high-end internal modules, it offers improved load capacity, achieving high power, torque, accuracy, and performance over a wide speed regulation range. This improves the overall stability of the converter.
【Intuitive Display】: The 220V to 380V three-phase VFD converter features an intuitive display and control buttons, simplifying parameter adjustments and providing a clearer data display. The removable control panel includes a 2-meter extension cable for remote operation, providing added convenience and flexibility. [Efficient Heat Dissipation]: This 220V to 380V frequency inverter is equipped with a high-performance DC heat sink for quiet operation. It effectively reduces the heat generated by the frequency converter during use and features intelligent start and stop control. [Widely Used]: This single-phase 220V to three-phase 380V frequency inverter is widely applicable to fans, pumps, ball mills, conveyor belts, textile machinery, compressors, drilling rigs, and other adjustable equipment. For heavier motor loads, choose a higher power frequency inverter for optimal performance.
【Stable Performance】: The frequency converter adjusts the motor's power to allow for variable speed operation while reducing voltage fluctuations in the power lines. Thanks to its high-end internal modules, it offers improved load capacity, achieving high power, torque, accuracy, and performance over a wide speed regulation range. This improves the overall stability of the converter.
【Intuitive Display】: The 220V to 380V three-phase VFD converter features an intuitive display and control buttons, simplifying parameter adjustments and providing a clearer data display. The removable control panel includes a 2-meter extension cable for remote operation, providing added convenience and flexibility. [Efficient Heat Dissipation]: This 220V to 380V frequency inverter is equipped with a high-performance DC heat sink for quiet operation. It effectively reduces the heat generated by the frequency converter during use and features intelligent start and stop control. [Widely Used]: This single-phase 220V to three-phase 380V frequency inverter is widely applicable to fans, pumps, ball mills, conveyor belts, textile machinery, compressors, drilling rigs, and other adjustable equipment. For heavier motor loads, choose a higher power frequency inverter for optimal performance.
Specifications:
Material: Flame-retardant ABS plastic
Color: Off-white
Rated input voltage: 220V single-phase
Rated output voltage: 380V three-phase
Rated power: 4KW
Output current: 6.5A
Input frequency: 50HZ
Output frequency: 0 - 600HZ
Product external dimensions: 18.2 * 13 * 8.7cm
Installation method: Wall-mounted, Cabinet-mounted
Cooling method: Air-cooled, with fan control
Package includes:
1 * Frequency converter
1 * 2 meter extension cable
1 * instruction manual (English)
Features
- BrandCOOCHEER
- Voltage220 V
- Amperage2 A
- Nominal intensityAC
- Power200 W
- ManoMano ReferenceME102639131
- MMID686951902360
- Product codeHD129C-260328241
