50A 6-10 Gauge Battery Connector Plug Pair Anderson Connector Battery Quick Connect Connector Plug

Name: 50A 6-10 Gauge Battery Connector Plug Pair Anderson Connector Battery Quick Connect Connector Plug
Brand: TINOR
SKU: TiR-UK-05241
Price: 10.79 GBP
Availability: InStock

~~£21.58~~

Sold by Tinor-GB

Product information

Description

General description

These 50A 6-10 Gauge Battery Connector Plug Pair Anderson Connectors are designed for quick and easy connections for winches and other electrical devices. They fit 6-10 gauge wires and support a voltage range of 12-36V, making them versatile for various applications.

Technical specifications

Rated Current: 50A

Rated Voltage: 600V

Contact Material: Copper, Silver-Plated

Contact Barrel Wire Size: 6/8/10/12 AWG

Maximum Wire Insulation Diameter: 0.44 inch (11.2 mm)

Contact Resistance AVG: 200 micro-ohm

Average contact resistance: 0.05 MΩ

Test Voltage: 2200 V (DC)

Insulation Resistance: 500 MΩ

No Load (contact/disconnect cycles): 10,000

Under Load (Hot Plug 250 cycles 120V): 50A

Average Unmating Force: 53N

Enclosure Material Flammability Rating: UL94 V-0

Operating Temperature Range: -20° to 125°

Installation

To install, simply insert the wire into the terminal pins and solder or clamp them. Then slide the pins into the back of the plug and lock them in place to complete the installation.

Usage

These connectors allow for quick connection and disconnection, making them ideal for use with winches and other electrical devices.

Other information

Package includes: 2 pieces Power connectors, 4 pieces Pin terminals, 2 pieces Rubber caps

Features

Brand
TINOR
Material
Copper
Pcs per pack
2
Terminal lug adapter only
Yes
ManoMano Reference
ME94199014
