Way Fuse Box, Fuse Holder with Negative Bus, Blade Fuse Blocks with 16 Fuses, 6 LED Indicators, Protective Case for 12V/32V Car, Boat, Marine, Truck, SUV

[Product name]: independent positive and negative poles, one input and multiple outputs, fuse box with LED display [1 input and 6 outputs]

【product model】:CS-1469A1

[Product net weight]: 191 g

[Product gross weight]: 223 g

>

【product size】87.75 x 85 x 36.5mm

[Packing method]: thick five-layer small white box with waterproof coating.

[Packing size]: 9.3 x 4.6 x 12.7cm.

[Product material]: PBT case, waterproof and dustproof PC cover, nickel-plated copper connection terminal, PPX40 sticker

[Rated input voltage]: 32V

[Rated input current]: 100A

【Maximum output current】 : 30 A for each circuit

[Display color]: red

[Main connection]: threaded bolt M5</ p>

【main thread】 #4-6

[Single connection]: M4 threaded bolt

【single wire】#12-16

[Indicator function]: When the red LED light is on, it means that the fuse has been disconnected and the fuse needs to be replaced in time to continue working.

[Product installation range]: Can be installed in cars, villas, RVs, buses, yachts, boats, etc.

< /p>

[Product use range]: It can be directly connected to any circuit in the car/boat [such as: ceiling lights, car headlights, wide lights, fog lights, warning lights, car refrigerators, car chargers, car fans, car TVs, etc.]

[Product accessories]: sticker X2; self-tapping screw X4; 20A fuse X4; 15A fuse X4; 10A fuse X2; A 5A fuse may damage the circuit or burn out the circuit or even cause a fire. Fuses protect electronic devices from overcurrent and can also prevent serious injuries caused by internal faults in electronic devices. Therefore, there is a rated specification for each fuse, and the fuse will blow when the current exceeds the rated specification. If the fuse is correctly placed in the circuit, when the current abnormally rises to the upper limit height and the upper limit temperature, the fuse will cut off the current, thereby protecting the operation of the circuit.

< /p>

[Product advantages]: [1] The product is made of high and low temperature resistant flame retardant PBT material, which meets the requirements of [the fuse holder has good mechanical strength, insulation, heat resistance and flame retardancy, and shall not be broken, deformed or damaged during use【2】 All busbars and fuse terminals are made of nickel-plated copper with corrosion resistance and excellent electrical conductivity

【3】All fasteners are made of stainless steel. The inlet and outlet ends of the fuse box are fixed with clamp screws, which allows for faster installation, and the fuse box is fixed with self-tapping screws, making installation easier and safer.< /p>

[4] The product has a red LED indicator design, which corresponds to each electrical appliance connected to the fuse. When the fuse is off, the red indicator light will light up and you can immediately know which fuse is broken, which is convenient for timely treatment.

[5] The product comes with a sticker that can be attached to the electrical appliance we connected according to the name on the sticker. When the fuse is broken and the red light is on, we can quickly know which electrical appliance has a problem, saving time and effort.

[6] The product comes with a double fuse. When used, the fuse is blown and can be immediately replaced with the spare fuse. The fuse is sent to multiple Abe, and the fuse for Abe can be selected according to the current electrical appliance
