9x 2-20mm ER32 Spring Collets Set + ER32 MT3 M12 Collet Chuck Holder Morse Taper

~~£71.99~~

£1Offered

To be applied on the payment page

Buying for your business?

Negotiated prices excl. VAT up to -20%

Create a pro account

Sold by DENCRESTUK

Product information

Description

General description

This collet set includes nine collets and one shank, designed to meet various clamping needs for milling machines. Crafted from premium materials with high-precision craftsmanship, it ensures sturdy and durable performance, providing stable and safe clamping results. The quick installation feature enhances efficiency, allowing for faster replacement of clamps.

Technical specifications

Color: Silver

Material: Spring Steel

Process: Turning, Milling, Grinding

Shank Type: MT3

Collet Type: ER32

Drawbar Thread: M12

Assembly Required: Yes

Collet Inner Diameter: 2mm/0.08in, 4mm/0.16in, 6mm/0.24in, 8mm/0.32in, 10mm/0.39in, 12mm/0.47in, 16mm/0.63in, 18mm/0.7in, 20mm/0.79in

Collet Outer Diameter: 33mm/1.3in

Collet Length: 40mm/1.57in

Shank Size: 50*140mm/1.97*5.5in

Tail Hole Diameter: 19mm/0.75in

Package Size: 20*17*10cm/7.87*6.69*3.94in

Gross Weight: 2kg/4.41lbs

Net Weight: 1.9kg/4.19lbs

Usage

The product is suitable for holding milling cutters, drill bits, and straight shank tools for various machining tasks, including boring, milling, drilling, tapping, engraving, CNC operations, spindle machines, and machining centers.

Other information

Burr-free edges for a smooth touch, preventing scratches during installation.

Tight interface for easy attachment and detachment of the collet.

Includes a professional lever for stable and high-precision drilling and milling work.

Images and videos are available for reference.

Notes: Please check sizes carefully before ordering and measure tool deviation before use. If deviation exceeds 0.05mm, correct it before cutting. Minimize tooling extension beyond the chuck and reduce cutting speed if abnormal vibrations occur.

Features

Brand
CNCEST
Warranty
1 year(s)
Max clamp diameter
20 mm
Material
Steel
Compatible drill
Standard drill
Weight
1900 g
Chuck tightening
Keyless self-tightening
Chuck
Morse taper shank
Insertion type
Morse taper shank
ManoMano Reference
ME94053082
MMID
709199935049
Product code
20211012010
EAN
762203053633
