ABS Material PL-05N NPN Proximity Sensor Switch Detection Distance 5mm

1、Proximity switch is a position sensor with switch output that can be connected with microcomputer

2、It also can drive directly from, electromagnetic relays, counters and contactor to achieve automatic control purposes.

3、It is a component widely used in automatic control industry for detecting, controlling, and non-contact switching.

4、When proximity switch is close to some target object, it will send out control signal.

5、It's widely used in machine, paper making, light industry for limiting station, orientation taking count, speeding trial etc.

Feature:

Proximity switch is a position sensor with switch output that can be connected with microcomputer

It also can drive directly from, electromagnetic relays, counters and contactor to achieve automatic control purposes.

It is a component widely used in automatic control industry for detecting, controlling, and non-contact switching.

When proximity switch is close to some target object, it will send out control signal.

It's widely used in machine, paper making, light industry for limiting station, orientation taking count, speeding trial etc.

Specification:

Model

PL-05N

Detection distance

5mm ± 10%

Set distance

0 - 4mm

Delay distance

<10% Detection distance

Standard object

Magnetic metal(Detection distance decreases for nonmagnetic metals)

Detect object

Iron 18*18*1mm

Response frequency

DC:0.5kHz AC:25Hz

Power

DC12 - 24V(6-36V); AC110 - 220V(36 - 250V)50/60Hz

Withstand voltage

AC1000V 50/60Hz

Effect of Voltage

±15% Rated voltage

Consumption current

N.P: <13mA, D: <0.8mA, A:<1.7mA

Control Output

N.P: <300mA, D:<200mA, A:<400mA

Circuit protection

A: Surge protection N.P.D: Surge protection, Reverse Connection Protection

Temperature range

-25 -+60℃

Isolation Resistance

>50MΩ

Material

ABS

Storage and use temperature

-30 - +65℃(No ice, no frost)

Storage and use humidity

35 - 95%RH

Package list:

1 * Switch

Note:

The actual product color may deviate from the photo due to light.

There may be a slight deviation in the measurement of product.
