AC 110-240V Digital PIDTemperature Controller Kits 0-400℃+ 25A SSR + 1m M6 K Type Thermocouple
You may also like
Compare with similar items
Product information
Description
1、High quality temperature control three-piece set, durable and reliable.
2、Digital temperature controller has high accuracy and good sensitivity.
3、PIN control including ON/OFF, step-type PID and continuous PID.
4、Energy saving and simple operation, stable performance.
5、LED display screen for clear reading.
Features:
High quality temperature control three-piece set, durable and reliable.
Digital temperature controller has high accuracy and good sensitivity.
PIN control including ON/OFF, step-type PID and continuous PID.
Energy saving and simple operation, stable performance.
LED display screen for clear reading.
Specification:
Condition: 100% brand new
Weight: 239g/8.4oz
REX - C100 thermostat:
Model: REX-C100FK02-V*AN DN
Measurement accuracy: ±0.5% FS
End to end compensation tolerance: 0 ~ 50 ℃ can be through the software to modify + 2 ℃
Resolution: 14 bits
Sampling cycle: 0.5 seconds
Power supply: AC 110-240V 50/60hz
Process value: (PV)
Set value: (SV)
Output, alarm and self-setting indicate: by LED
PIN control: including ON/OFF, stepper PID and continuous PID
Self-adjusting control: Yes
Delayed output: contact capacity 250V AC 3A (resistance load)
Alarm function output: No
Proportional band (P) : 0 ~ full range (ON/OFF control set to 0)
The testing temperature range: 0 ~ 400 ℃
Insulation resistance: > 50M ohm (500V DC)
Insulation resistance: 1500V AC/min
Insulation resistance: power consumption <10VA
The environment of service: 0 ~ 50 ℃
Non-corrosive gas environment 30 ~ 85% RH
Temperature input type: K-type thermocouple
Size: 48 * 48 * 110mm / 1.9 * 1.9 * 4.3in
K Type Thermocouple:
Length: 1m
Diameter of sensor: 4.5mm
Temperature range: 0 ~ 1300 ℃
Internal insulation: fiberglass
External shielding: insulation shielding
Solid-state relay:
Output voltage range: standard
Output current: 25A
Input voltage: DC 3-32V
Output voltage: 24-480V AC
Package List:
1 x REX-C100 Temperature Controller
1 x K-type Thermocouple
1 x Solid-state Relay
