AC/DC Leakage Current Meter without Clamp, CT 0mA-60.0A, Safe and Accurate, Data Retention
Of which environmental contribution £0.01 including VAT.
Sold by Sinocor GmbH
You may also like
Compare with similar items
Product information
Description
Specification:
Item Type: Leakage Current Tester
Material: ABS
Model: ETCR6000B
Measurement Function: Automotive DC dark current, leakage current, etc., other AC and DC currents, leakage current measurement
Power Supply: 1 x 6F22 9V battery, 100 hours of continuous use (battery not included)
Test Method: Clamp CT, non-Measurement of
Jaw Size: Approx. 16x18mm / 0.6x0.7in
Range: 0mA-60.0A AC/DC
Resolution: 1mA AC/DC
Accuracy: ±2%Rdg±5dgt (23℃±5℃, less than 75%Rh)
Display Mode: 4-digit LCD screen
Sampling Rate: 2 times/sec
Frequency Response: AC 45 Hz-400 Hz
Polarity Indication: Automatically detects DC current, displays a "-" sign; USB Interface: With a USB interface, stored data can be downloaded to a computer, saved, and printed
Communication Parameters: Baud Rate 9600, Data Bits 8, Stop Bits 1, Parity Bits None
Support Functions: Data Hold, Display Overflow, automatic shut-off, battery voltage
Operating current: 10 mA
Operating temperature and humidity: -10℃-50℃; below 80% RH
Temperature error limit: -10℃-0℃ and 40℃-50℃, maximum error increases by 2% of the reading
Package list:
1 x AC/DC leakage current meter (battery not included)
1 x CD
1 x USB cable
1 x manual
1 x bag
Item Type: Leakage Current Tester
Material: ABS
Model: ETCR6000B
Measurement Function: Automotive DC dark current, leakage current, etc., other AC and DC currents, leakage current measurement
Power Supply: 1 x 6F22 9V battery, 100 hours of continuous use (battery not included)
Test Method: Clamp CT, non-Measurement of
Jaw Size: Approx. 16x18mm / 0.6x0.7in
Range: 0mA-60.0A AC/DC
Resolution: 1mA AC/DC
Accuracy: ±2%Rdg±5dgt (23℃±5℃, less than 75%Rh)
Display Mode: 4-digit LCD screen
Sampling Rate: 2 times/sec
Frequency Response: AC 45 Hz-400 Hz
Polarity Indication: Automatically detects DC current, displays a "-" sign; USB Interface: With a USB interface, stored data can be downloaded to a computer, saved, and printed
Communication Parameters: Baud Rate 9600, Data Bits 8, Stop Bits 1, Parity Bits None
Support Functions: Data Hold, Display Overflow, automatic shut-off, battery voltage
Operating current: 10 mA
Operating temperature and humidity: -10℃-50℃; below 80% RH
Temperature error limit: -10℃-0℃ and 40℃-50℃, maximum error increases by 2% of the reading
Package list:
1 x AC/DC leakage current meter (battery not included)
1 x CD
1 x USB cable
1 x manual
1 x bag
