Automotive brake fluid moisture analyzer pen-type brake fluid tester

5 LED Car Vehicle Test Tool for Brake Fluid Tester Thank you for choosing this brake fluid tester. The tester can be used as a digital brake fluid tester suitable for determining brake fluid quality. Developed for professional use in automotive repair shops and maintenance. The quality is tested and indicated by five LEDs in terms of the percentage of water in the brake fluid. Ready to test the brake fluid: Unscrew the brake fluid reservoir and remove the cap from the brake fluid tester. Immerse the test probes in the brake fluid up to the plastic edge of the device.

To check the fluid quality

Press the button to turn on; the green LED will light up. Insert the tester into the reservoir for one second, and the tester result will be correctly indicated by the LEDs.

Press the button again to turn off. The tester will automatically turn off after approximately 15 seconds of inactivity.

Tester Specification:

1. To check the quality of brake fluid

2. 5 LEDs to indicate the percentage of water in the brake fluid

3. Automatically turns off

4. Operates on one LR03 AAA 1.5V battery (not included)

Tester Instructions:

The brake fluid detection pen is based on changes in conductivity to determine the brake fluid's moisture content. It clearly shows the extent of the moisture content with an LED; a high moisture content will result in a lower boiling point, affecting braking performance.

Red indicates that the brake fluid must be replaced immediately, green indicates good condition, and yellow indicates acceptable condition but replacement is needed soon.

1. Green LED illuminates = Water content in brake fluid (H2O) 1.5%, brake fluid is good.

2. Yellow LED illuminates = Water content in brake fluid (H2O) = 1.5% to 3%, can continue to use, retest in six months.

3. Red LED illuminates = Water content in brake fluid (H2O) 3%, can no longer be used, brake fluid must be replaced. Red LED: Change brake fluid.

4. Flashing red LED: Battery replacement.

5. Yellow LED: Low moisture content, recheck in six months.

6. Green LED: Brake fluid lines / cell range

Tester Features:

Five LED indicators show more precise test results.

Tests DOT 3, DOT 4, and DOT 5 brake fluid

Press the switch to turn on the power. The green LED indicates a healthy battery. If the green LED does not light up, the battery needs replacing.

Automatic shut-off

Technical Parameters:

Green: Battery OK, meaning the brake fluid does not contain water.

Green/Yellow: Brake fluid has a water content of less than 1%, resulting in better brake fluid performance and ease of use.

Green/Yellow/Yellow: Brake fluid has a water content of approximately 2%, meaning the brake fluid can continue to be used.

used.

Green/yellow/yellow/red: Brake fluid with a water content of approximately 3%, brake fluid replacement recommended.

Green/yellow/yellow/red/red: Brake fluid with a water content of at least 4%, the brake fluid must be replaced immediately, as this is extremely dangerous.

Caution:

1. Replace the battery if the green LED no longer illuminates after pressing the power button. Wash the test probe with tap water after use.

2. In case of skin contact with brake fluid, thoroughly wash the affected skin or clothing with water.

3. Do not expose the brake fluid to the atmosphere for extended periods as it is highly hygroscopic!

Package Contents

1x Brake Fluid Tester

Please note: No battery is included. Please purchase one from your local store. The battery model is LR03 AAA.
