Dewalt DWS780 305mm XPS Sliding Compound Mitre Saw 1675W 110V + DE7033 Leg Stand

DEWALT DWS780 305mm Sliding Compound Mitre Saw 1675W 240V Version + DE7033 Leg Stand

The DEWALT DWS780 is a 305mm Compound Slide Mitre Saw offering outstanding cutting performance in both small profiles and large construction timbers. XPS shadow line cut indicator which provides a fast accurate alignment of the blade while illuminating the workpiece for increased productivity no adjustment required.

Heavy-duty durability with the ability to fully adjust the machine to maintain accuracy over the life of the tool. Quick release bevel stop setting provides accurate and simple setting of bevel angles up to 49° left and right. Cam action mitre lock function makes mitre setting faster and easier allowing the user to quickly angles between 0° - 50° left and 0° - 60° right.

The 305mm Mitre Saw is engineered for repeatable accuracy with dual horizontal rails and a stainless steel detent plate with common angles at 0, 15, 22.5, 31.6, 35.3 and 45 degrees, the 1675 watt motor also offers a maximum cutting capacity of 305 x 77mm. Other features include XPS crosscut positioning system for the ultimate in accuracy and visibility with no calibration needed and machined side handles for increased portability on site.

Features

LARGE DUAL SLIDING FENCE: Provides maximum support in large material cuts at any angle or combination of angles
COMPACT & LIGHTWEIGHT: Huge cut capacities, with a lightweight compact design for easy transport around the jobsite
XPS SHADOWLINE: Provides fast accurate alignment of the blade with no adjustment required
STAINLESS STEEL DETENT PLATE: Robust and easy to recalibrate, with common angles at 0, 12.25, 15, 22.5, 31.6 and 45 degrees
AIRLOCK DUST PORT: AirLock compatible dust extraction for simple connection
CAM LOCK MITRE CONTROL: Makes mitre setting faster and easier, allowing to quickly adjust angles between 0° - 50° left and 0° - 60° right
DOUBLE BEVEL: Intuitive bevel lock with machined stops provides accurate and simple setting of bevel angles up to 49° left and right
DEPTH STOP: Allows the adjustment of the cutting depth for grooving and rebating applications
MACHINED BASE & FENCE: Designed, machined and checked to the highest standards of accuracy to deliver 0.1° accuracy
3 YEAR GUARANTEE: Tool covered by extended warranty, subject to registration

Supplied with: 1 x 305mm 60 Tooth Blade, 1 x Blade Spanner, 1 x Dust Bag and 1 x Material Clamp

The Dewalt DE7033 heavy-duty short beam leg stand accommodates all DeWalt mitre saws.

The DE7033 stand is shorter than its big brother the DE7023, which enables this stand to fit into the boot of larger cars or in the back of small vans. The stand is 1.1m in length but can extend up to 2.5m to support larger pieces of timber. Folding legs complete its compact design and portability.

It has a lightweight aluminium construction, that provides portability in and around the jobsite (only 14kg), the 1.1 metre beam extends to support up to 2.5 metres for use with large workpieces and the beam can support up to 227kg.

Work stops can be converted into end stops for repetitive cutting to length. Integral folding legs avoid unnecessary assembly and the integrated carry handle provides ease of transportation.
