Digital PID temperature controller – REX-C100 – Range 0 to 1300 °C, LED display, built-in alarm, universal voltage 110–240 V

1. Professional Kit: This temperature controller adopts industrial-grade professional auto-tuning PID technology. Compared to traditional PID control, it features fast temperature control, quick response, minimal overshoot, and high accuracy.
2. Practicality: This temperature controller is useful for intelligently controlling temperature and can help the operator achieve good results with simple operation.
3. Speciality: This multifunctional controller features a special microprocessor-controlled switching power supply and SMT.
4. Wide Application: It can be widely applied in electric power, chemical industry, injection molding, food processing, incubators, ovens, and many other types of equipment.
5. Durable: The probe uses a stainless steel casing and resin sealing treatment, making it waterproof and rust-resistant for a long service life.

Specification:

Features:
Professional Kit: This temperature controller adopts industrial-grade professional auto-tuning PID technology. Compared to traditional PID control, it offers fast temperature control, quick response, minimal overshoot, and high accuracy.
Convenient: This temperature controller is useful for intelligent temperature control and can help the operator achieve good results with simple operation.
Specialty: This multifunctional controller features a special microprocessor-controlled switching power supply and SMT.
Wide Application: It can be widely applied in electric power, chemical industry, injection molding, food processing, incubators, ovens, and many other industries. Equipment.
Durable: The probe uses a stainless steel casing and resin sealing treatment, making it waterproof and rust-resistant for a long service life.
Specification:
REX-C100 Thermostat
Model No.: rex-c100fk07-v *AN
Measurement Accuracy: 0.5% FS
End-to-End Compensation Tolerance: ±2° (Can be modified by software in 0~50?)
Resolution: 14 bits
Sampling cycle: 0.5 seconds
Power supply: AC 110-240V 50/60Hz
Process value (PV), setpoint value (SV)
Output, alarm, and self-tuning can be indicated by LEDs
PIN control (including ON/OFF, stepper PID, and continuous PID)
Self-tuning control
Delayed output: 250V AC 3A contact capacity (resistor load)
Alarm function output: 2 channels
Proportional band (P): 0 ~ full range (ON/OFF control set to 0)
Test temperature range: 0 ~ 1300 Ω
Insulation resistance: > 50M ohm (500V DC)
Insulation resistance: 1500VAC/min
Insulation resistance: power consumption
Operating environment: 0 ~ 50°C
Non-corrosive gas environment 30 ~ 85% RH
Dimensions: 48*48*110mm
Two K-type thermocouple probe cables
Length: 1m
Sensor diameter: 4.5mm
Temperature range: 0 ~ 400°C
Internal insulation: fiberglass
External shielding: insulating shield
Maximum 40A SSR (solid-state relay)
Output voltage range: standard
Output current: 40A
Input voltage: DC 3-32V
Output voltage: 24-480V AC
Weight: 265g / 9.3oz (approx.)

Package List:
1 x REX-C100 PID Temperature Controller (0-1300°F)
1 x K-Type Thermocouple/Temperature Sensor (0-400°F)
1 x 40A Max Solid State Relay
Note:
Please note that the new and old types of this product will be sent randomly, and make sure you don't mind this before ordering.
Temperature range of the temperature controller: 0-1300 degrees
Temperature range of the sensor: 0-400 degrees
