Dirt Bike Engine, 125CC Motorbike 4-Stroke CDI Motor Engine Pit Dirt Bike ATV Quad Kit Air-Cooled Clutch Engine Starter Complete Kit

~~£435.99~~

£6Offered

To be applied on the payment page

Buying for your business?

Negotiated prices excl. VAT up to -20%

Create a pro account

Sold by DENCRESTUK

Product information

Description

General description

Our 4-stroke engine is a powerhouse designed to elevate your riding experience. With cutting-edge technology and precision engineering, this engine is a testament to performance and reliability. Equipped with high power and a large fuel tank, it produces great power and helps you get the job done quickly without the need for frequent refueling.

Technical specifications

Engine Type: 4-Stroke, Single Cylinder

Engine Displacement: 125cc

Cooling System: Air Cooling

Transmission: 4-speed, Manual Clutch (1-N-2-3-4)

Clutch: Wet Multi-disc Clutch

Lubricant: SAE 15W/40-SE, Four-stroke Gasoline Engine Oil

Compression Ratio: 9.0:1

Bore*Stroke: 52.4*55.5 mm / 2.06*2.18 in

Maximum Power: 6.5KW / 7500 rpm ± 375 rpm

Rated Power: 5.6KW / 7500 rpm ± 375 rpm

Max. Torque: 8.0 Nm / 5000 rpm ± 250 rpm

Idle Speed: 1500 rpm ± 100 rpm

Fuel Consumption: ≤367g/kw.h

Ignition System: CDI

Starting Mode: Kick Starter

Spark Plug: A7TC

Carburetor Type: PZ22

Primary Reduction Ratio: 3.722

Lubricant Capacity: 900ml / 30.43oz

Item Weight: 19.1kg / 42.1lbs

Product Size: 44*29*22cm / 17.32*11.4*8.66in

Gross Weight: 21.5kg / 47.4lbs

Package Size: 48*37*35cm / 19*14.6*14in

Compatibility and accessories

This engine is compatible with the following models: CRF50, CRF70, XR50, XR70, Z50, Z50R, CT70 Mini Trail, Z50, Minitrail monkey, XL70, ST70, QA50, QR50, CL70, SL70, 70 Pass, ST 90K2, ST 90K1, CS 90, SL 90, ZB 50. Package includes 1* 4-stroke Engine and all accessories for installation.

Installation

Assembly is straightforward with complete installation accessories provided. Professional installation is highly recommended. Please note that the installation manual is not included.

Usage

Before use, carefully check the cable, power supply, and take proper protective measures to avoid potential safety hazards. It is advisable to read the product label and pay attention to safety precautions.

Other information

Please allow for slight color differences caused by lighting and a 1-3cm error due to manual measurement. Ensure you do not mind these before ordering.

Features

Brand
CNCEST
Warranty
1 year(s)
Height
220 mm
Width
290 mm
Material
Metal
ManoMano Reference
ME94435672
MMID
418264062853
Product code
20211012317
EAN
756383487005
