Double splicing machine for wooden frames Holzmann knf2230v

Name: Double splicing machine for wooden frames Holzmann knf2230v
Brand: HOLZMANN
SKU: HOL-KNF2_230V
Price: 757.39 GBP
Availability: InStock

Sold by GLS72

Product information

Description

General description

The HOLZMANN KNF2_230V dovetail jointer features two cutter spindles, making it perfect for producing two dovetail joints in a single work stroke. It is designed for creating picture frames, window frames, and various other frame joints quickly and easily without the need for glue.

Technical specifications

Motor power S1: 600 W

Voltage: 230 V / 50 Hz

Protection class: II

Table dimensions: 380 x 220 mm

Installation dimensions: 400 x 480 x 550 mm

Maximum workpiece thickness: 85 mm

Sound pressure level: 102 dB(A)

Maximum milling capacity: 55 mm

Milling spindle speed: 12,000 - 27,000 rpm

Packaging dimensions: 450 x 480 x 555 mm

Net weight: 16 kg

Gross weight: 19 kg

Compatibility and accessories

Includes 2 cutters, shape W-2

2 collets (6 mm and 8 mm)

Cutter adjustment gauge

Installation

Manual workpiece clamping

Adjustable cutter stops for positioning the workpiece

Features

Brand
HOLZMANN
Power source
Corded
Material
Wood
Operating Mode
Manual
Weight
16 kg
