Double Throw Knife Disconnect Switch Orange Red 3P Terminal Connection Electric Supplies 32A

1、The product is small in size and large in circulation.

2、The design is novel and can be installed and wired without the need for a cover.

3、Applicable to industrial enterprises and household electrical equipment, for conversion network and self-generated lines

4、Generally suitable for dual circuit switching

5、Wiring method with terminal connection, it has stable performance

Features:

1. The product is small in size and large in circulation.

2. The design is novel and can be installed and wired without the need for a cover.

3. Applicable to industrial enterprises and household electrical equipment, for conversion network and self-generated lines

4. Generally suitable for dual circuit switching

5. Wiring method with terminal connection, it has stable performance

Specification:

Condition: 100% Brand new

Item Type: Double Throw Knife Disconnect Switch

Product Use: Dual Circuit Switching

Shell Color: Orange Red

Rated Current: 32A, 63A, 100A

Rated Voltage: 380V

Handle Material: Flame Retardant PA

Fixing Method: Nail Hole

Shell Material: ABS

Main Material: Copper

Base Material: DMC

Wiring Method: Terminal Connection

Material Characteristics: Coating

Optional Style: 3P 32A, 3P 63A, 3P 100A

Package List:

1 x Double Throw Knife Disconnect Switch

4 x Screws

Note:

Normal working conditions and installation conditions:

The ambient air temperature is not higher than +40℃, not lower than -5℃.

The altitude of the installation site does not exceed 2000m.

Humidity: When the maximum temperature is +40℃, the relative humidity of the air does not exceed 50%. At lower temperatures, higher relative humidity can be allowed, for example, 90% at 20℃. Special measures should be taken for condensation that occasionally occurs due to temperature changes.

The pollution level of the surrounding environment is level 3 or below.

The switch shall be installed in a place where there is no significant shaking, shock vibration and no rain or snow. At the same time, the installation site should be free from explosive atmospheres, and there should be no gas or dust in the medium to corrode the metal and damage the insulation.

Before installation, check whether the switch is intact and flexible.

Working conditions should be in accordance with the regulations.

The switch should be regularly maintained and adjusted to remove dirt and keep it clean so that the contacts work in good condition.
