Draper Hydraulic Lift Table 225kg Capacity Model 99814 for Heavy-Duty Material Handling

General Description

• This hydraulic lifting table is designed to lift loads up to 225kg. It features a steel tabletop with a rubber mat to prevent damage and slipping. The table is equipped with a foot-operated hydraulic pump and a separate hand-operated release for easy height adjustment. It includes safety features such as an overload valve and a locking mechanism at 590mm height, ensuring secure positioning during use. The table is mobile, fitted with two fixed and two swivel wheels with brakes for smooth movement and stability.

Technical Specifications

• Capacity: 225kg
• Lift height range: 225-720mm
• Table size: 710 x 453mm
• Locking height: 590mm
• Lift height: 495mm
• Handle working height: 895mm
• Wheel diameter: 100mm
• Weight: 39kg

Compatibility and Accessories

• Designed for lifting and transporting heavy loads in workshops, garages, and industrial settings
• Fitted with four wheels (two fixed, two swivel with brakes) for mobility

Installation

• No complex installation required; simply position the lift table on a flat surface and ensure wheels are locked during use

Usage

• Use the foot pedal to raise the table to the desired height
• Use the hand-operated release to lower the table safely
• Lock the wheels when stationary for stability

Other Information

• Manufactured to EN 1494 standards for safety and durability
