EDF Meter Single Phase DIN Rail Energy Meter 5-80A 220V 50Hz Electronic KWh Meter with LCD Backlight Digital Display DDM15SD White

Sold by B2C Agro Top Garden GmbH and 1 other seller

Product information

Description

General descriptionThe EDF Meter Single Phase DIN Rail Energy Meter is designed for accurate and reliable measurement of electric energy. It features an LCD backlight digital display that alternately shows electricity consumption, voltage, current, and power, making it easy to monitor energy usage.Technical specificationsModel: DDM15SDReference voltage: 220V/50HzCurrent range: 5A-80APower: 17000WAccuracy: First classDisplay: Backlight LCD digital displayInstallation: DIN rail of 35mmPole width: 17.5mmWiring method: Up-Out and Down-In / Up-In and Down-OutAmbient temperature: -20℃ to +50℃Item size: Approx. 7.8 × 3.7 × 6.6cm (3.1 × 1.5 × 2.6in)Item weight: 200g (7.1oz)Package size: 8 × 7 × 4cm (3.1 × 2.8 × 1.6in)Package weight: 300gInstallationThe energy meter is designed for easy installation on a 35mm DIN rail. It supports multiple wiring methods, allowing for flexible installation options.UsageThis energy meter is ideal for monitoring electricity consumption in residential or commercial settings, providing real-time data on voltage, current, and power usage.Other informationThis energy meter does not have a reset function.Package includes: 1 × energy meter
