Energy Meter,Digital LCD Electronic Energy Meter KWh on DIN Rail 3 Phase 4 Wire 3 Phase 80A
Sold by A and S and 1 other seller
You may also like
Compare with similar items
Often purchased together
Product information
Description
Anti-electromagnetic interference, low power consumption, high precision, high overload, high stability, anti-theft and so on. Compatible with most AMR systems. Complies with IEC 62053-21 and DIN 43864 standards. With four-pin width (17.5mm module) according to DIN43880 standard. It can show the power status (A, B, C), pulse signal (red) - Total four LED indicators, 8-digit display, 6 + 2 digit display (999999.11 kWh), the data is shown accurately. Insulating material housing - No current leakage, guarantees your safety during use and also saves space. Features: Model: XTM024. Standard: IEC62053-21. Display: 8-digit LCD display. Accuracy class: 1.0. Voltage: 3 x 230/400 V. Current: 5 (80 A). Starting current: 0.04%. Frequency: 50 Hz. Pulse: 400 Imp/kWh. Package dimensions: approximately 11 cm x 8 cm x 7 cm. Package contents: 1 x three-phase four-wire gauge. 1 x user manual (English language not guaranteed). Attention: * The actual color of the product may be slightly different from the pictures shown on the website caused by many factors such as the brightness of the display and the brightness of the light.
Features
- BrandWOIYIC
- Amperage80 A
- Accuracy classClass 1.0
- Control functionYes
- Frequency50 Hertz
