Environmental Signal Output 0-5V 360 Degree Polycarbonate Transmitter Wind Speed Sensor Anemometer (9.3 x 7.3 Inches)
Buying for your business?
Negotiated prices excl. VAT up to -20%
You may also like
Compare with similar items
Product information
Description
1. Small and lightweight, easy to carry and assemble, 8-way adjustable, and easy to use. 2. It is made of polycarbonate, which offers high mechanical strength, high hardness, corrosion resistance, and rust resistance. 3. Anti-exposure, high impact resistance, long service life, suitable for long-term use in outdoor environments. 4. With a smooth internal bearing system, data collection accuracy is effectively ensured, and operation is more convenient. 5. High-performance bearings, low rotational resistance, accurate measurement, electromagnetic interference protection, can be applied to both four-wire and three-wire connections.
Specification:
Condition: 100% Brand New Item Type: Wind Direction Sensor. Material: Polycarbonate Wide Voltage: 10-30V DC Power Input.
Application: Widely used for wind direction measurement in greenhouses, environmental protection, weather stations, ships, docks, livestock farming, and other environments. Parameter: DC Power Supply (default) 10-30V DC; Maximum Power Consumption Output Voltage 1.2W; Transmitter Circuit Operating Temperature -20°C to +60°C, 0%RH-80%RH; Dynamic Response Time ≤0.5s; Output Signal Voltage Output 0-5V; Load Capacitance Output Voltage Resistance ≤600Ω Calculation Method: Output Comparison Table 0-5V Output Value (V) Corresponding Wind Direction 0 North Wind 0.7143 Northeast Wind 1.4286 East Wind 2.1429 Southeast Wind 2.8571 South Wind 3.5714 Southwest Wind 4.2857 West Wind 5 Northwest Wind Product Size: Approx. 23.5 x 18.5 cm / 9.3 x 7.3 inches Weight: Approx. 315g / 11.1oz Common Problems and Solutions: No Output or Output Error Possible Causes: 1) The error corresponding to the range causes the PLC calculation error. Refer to the range technical specifications. 2) The wiring method is incorrect or the wiring sequence is incorrect. 3) The supply voltage is incorrect (24V supply for the 0-10V type). 4) The distance between the transmitter and the collector is too long, causing signal interference. 5) The PLC's collector port is damaged. 6) Physical damage.Package List:
1 x Wind Direction Sensor 1 x Cable 1 x Screw Kit (4 x Screws, 4 x Nuts)
Note:
1. The user should not disassemble the sensor themselves and should not touch the sensor core to avoid damaging the product. 2. Keep the sensor as far away as possible from high-power interference equipment to avoid inaccurate measurements, such as inverters, motors, etc. When installing or removing the transmitter, the power supply must be disconnected first, and water inside the transmitter can cause irreversible damage.
3. Prevent chemicals, oil, dust, etc., from directly entering the sensor; do not use it for extended periods under condensation or in extreme temperature environments; and avoid sudden temperature changes.Features
- BrandOTHERS
- ColourBlack
- MaterialPolycarbonate
- Measuring methodDigital
- ManoMano ReferenceME223243609
- MMID791493417719
- Product codeKrlin-39865
