Maximum flexibility thanks to flat housing for minimum wall distance
Even more precise thanks to angle setting with snap-in points and indentation (-1° and/or 47°)
Guide wedge for safer work and simple positioning in existing joint
Good view of scribe line and saw blade thanks to the newflush and moveable viewing window
Improved dust extraction thanks to the new shape of the extraction duct
Simpler operation with the double cutting depth scale (with/without guide rail)
More benefits:
Splinterguard
FastFix blade change
Play adjustment without the need for tools
Quick brake
Main applications:
Precise circular in materials up to 55 mm thick
Cutting interior doors to length using guide rail and circular saw
Manufacturing expansion joints in parquet flooring and false joints
Cutting chipboard to size
Cutting and processing plasterboard
Power consumption 1200 W
Idle engine speed 2000-5200 min
1 Saw blade diameter 160 mm
Inclination -1 / +47 °
Cutting depth 0-55 mm
Cutting depth at 45 degrees 0-43 mm
Cutting depth at 45°/90° 0-43/0-55 mm
Connection Ø d/e 27/36 mm
Weight 4,5 kg
Fine tooth saw blade HW W 48tooth
Guide rail FS 1400/2
Splinterguard
Viewing window
SYSTAINER SYS 4 T-LOC case
