FNIRSI WD-02 Wall Detector Scanner

FNIRSI WD-02 Wall Detector ScannerWall Scanner | Wood and Metal Detection | Live Wire Detection | LCD Display | Portable Design

The FNIRSI WD-02 Wall Detector Scanner is a portable detection tool designed for locating hidden objects inside walls, ceilings and floors during renovation, installation and drilling work.

It is suitable for detecting wood structures, metal objects and live AC wires, helping users reduce the risk of accidental damage during household and professional construction tasks.

Key Features

• Multifunction detection: suitable for locating wood, metal objects and live AC wires inside building surfaces.
• Precise detection: designed for locating edges, centers, studs, pipes and live wires.
• Portable construction: compact size supports convenient handling during daily use.
• Clear information display: screen shows detection depth, center position and material type.
• Indicator guidance: visual indicators help show target distance during scanning.
• Audible alerts: beep signals assist with locating targets and center positions.
• HPC module: supports improved anti-interference performance and calculation speed.
• Center marking design: built-in center hole helps with accurate drilling and marking.

Technical Specifications

• Model: WD-02
• Detection depth for wood: up to 38 mm
• Detection depth for non-ferrous metal: up to 100 mm
• Detection depth for ferrous metal / rebar: up to 120 mm
• Detection depth for AC wire: up to 50 mm
• Battery: built-in 3.7 V 300 mAh lithium battery
• Charging port: USB-C
• Charging parameters: DC 5 V 0.5 A
• Operating temperature: -10°C to +50°C
• Weight: Approx. 210 g
• Dimensions: 138 × 68 × 22 mm

Applications

• Wall drilling and installation work
• Home renovation
• Electrical installation
• Pipe and stud locating
• Safe appliance mounting

Package Contents

• 1 * FNIRSI WD-02 Wall Detector Scanner
• 1 * Charging Cable
• 1 * User Manual
• 1 * Storage Bag

The FNIRSI WD-02 provides a practical solution for detecting hidden structures and live wiring before drilling, mounting and installation work.
