Garage door remote control receiver - RX MULTI 300-900MHz - 433-868MHz - AC/DC 9-30V - With remote control
Sold by Selphora
You may also like
Compare with similar items
Product information
Description
Specifications: 1) Range: 50-150 meters. 2) Very small size: 5.5 cm x 4.5 cm x 1.0 cm. 3) One receiver can operate with 400 codes. 4) It does not interfere with other remote controls and receivers. 5) Brand selector: With 8 DIP switches, the user can create different combinations for different brands of remote controls. Power input selector: The receiver can operate on AC/DC 9V~30V. However, it is best to change the DIP switch according to the power consumption. If the input is above 24V, short pins 2 and 3; short pins 1 and 2 if the input is below 24V. Color: White + Black. Material: ABS. Programming a new remote control: 1) Select the correct brand of remote control to program by moving the DIP switches UP or DOWN. For example, for 433.92 MHz remote controls, simply move DIP switch 7 to the UP position. 2) Press the learning button. The LED will light up. 3) Press the remote control button; the LED will flash 4 times. This indicates that the remote control has been successfully programmed. 4) Repeat step 2 for another button. 5) The programming procedure for the second channel is the same. To erase all data from the memory card: press and hold one of the learning buttons. The LED will begin to flash. Continue holding the button until the LED turns off. All data stored on the memory card will be permanently erased and cannot be recovered. Compatible brands: All 433.92 MHz fixed-code remote controls. Package contents: 1 x receiver, 3 remote controls. Only the above package contents are included; other products are not included. Note: Light reflection and different displays may cause the item's color to be slightly different from the real thing. The measurement allowed error is +/- 1-3 cm.
Features
- BrandOTHERS
- Length5.5 cm
- Height1 cm
- MaterialAcrylonitrile butadiene styrene (ABS)
- Light sourceNone
