Heavy Duty Jack, 20 Ton Hydraulic Jack Cylinder Oil Pump Hydraulic Cylinder Lifter Hollow Cylinder Ram, for Bending, Straightening and Pulling on Trucks, Tractors and Heavy Equipment

#1 in sales

~~£189.99~~

£1Offered

To be applied on the payment page

Offer valid today only.

Sold by DENCRESTUK

Product information

Description

General description

This heavy-duty hydraulic jack is designed for bending, straightening, and pulling on trucks, tractors, and heavy equipment. Made from sturdy 45# steel, it combines power with compact portability, making it an essential tool for various engineering projects. Its multiple functions include lifting, jacking, pushing, and pulling, ensuring reliability and efficiency in demanding work environments.

Technical specifications

Material: 45# Steel

Discharge Force: 20T / 44,092.45 lbs

Outside Diameter: 100mm / 3.94in

Rated Stroke: 50mm / 1.97in

Actual Stroke: 60mm / 2.36in

Piston Diameter: 54mm / 2.13in

Bore Diameter: 27mm / 1.06in

Body Height: 160mm / 6.3in

Net Weight: 8.4kg / 18.52lbs

Gross Weight: 8.8kg / 19.40lbs

Package Size: 25*23*20cm / 9.84*9.06*7.87in

Hand Pump Working Pressure: 70MPa

Hand Pump High-Pressure Flow Rate: 2.2CC

Hand Pump Low-Pressure Flow Rate: 13CC

Hand Pump Reservoir Capacity: 900CC

Compatibility and accessories

Compatible with CP-700 series manual pump (not included)

Quick Coupling Standard: ZG3/8

Installation

Easy installation using a standard ZG3/8 threaded quick coupling

Ensure all cylinders are connected to a solid, flat jacking surface to avoid issues

Usage

Can be used vertically, horizontally, and in an inverted orientation

Ideal for construction sites, petroleum, electric power, metallurgy, chemical industry, ships, bridges, and steel industries

Other information

Dustproof cap to prevent impurities from entering the quick coupling

Smooth, burr-free surface for hand protection during maintenance

Ergonomically designed for a comfortable grip

Note: Not suitable for jacking cars

Ensure proper tightening of connectors to prevent oil leakage

Minor oil on the quick coupling is normal and does not affect functionality

Allow for slight color differences and measurement errors
