Description
Features:
1. The diaphragm pump combines the advantages of a self-priming pump and a chemical pump. Installed in a dry and well-ventilated place, the pump cannot work in water.
2. Adopts many kinds of imported corrosion-resistant materials, self-priming, thermal protection, smooth operation, long-time continuous no-load operation, long-time continuous load operation.
3) Fully sealed, stable pressure.
4) The rubber bracket can absorb vibration when the pump is working.
5) When the water pressure is too high, the pump will protect itself to work normally, the water pipe will not burst, it is safe and durable.
6) Pressure protection: pressure switch power protection.
7) Maximum flow 5-6 L/min, maximum pressure 7.0 kg, both non-adjustable.
8) Working mode: intermittent duty (different working pressure at different times, continuous work).
9. Using fluid: water or solvent, PH value 5-8, oil. Lifespan: More than 500-1000 hours of continuous work.
10. Pressure switch features: When the water is turned off, the power supply is automatically cut off and the motor stops. When the water is turned on, the motor automatically turns on. 11. The shell is made of ABS plastic. 12. The maximum pressure has been set at the factory and cannot be adjusted during use.
Specifications:
Volts: 12V DC.
(PS: 220V AC (transformer required for operation)
Amps: 6A
Rated power: 72W
Pressure: 7kg
Flow rate: 6L/MIN (6.0 liters/minute)
Working medium: No oil, no strong corrosive, no acid or alkali, no solid particles of liquid;
Temperature of the medium: 0℃-100℃ at import and export
Size: 10mm
Size: 16.5×10× 6.2 cm
Type: Threaded
Weight: 600 g (threaded)
- Note!
We need to conduct a waterproof test for each product before shipment to confirm that the customer can use it properly. Therefore, the received products may have a little water or water stains. We assure you that the product is brand new.
Features
- BrandWOIYIC
- Length16.5 cm
- Width10 cm
- Height1 cm
- Weight0.6 kg
