Infrared Thermal Imager Portable Infrared Imaging Device Visual Temperature Tester for Construction HAVC Factory Test
Sold by STUNACY
You may also like
Compare with similar items
Product information
Description
1、THERMAL IMAGING This is a small, lightweight multifunctional thermal imager. Large screen, data at a glance. The screen displays the maximum temperature, minimum temperature, and temperature of the tracking center.
2、HIGH ACCURACY TESTING Temperature measurement range is ‑40℃ ‑ 300℃, accuracy is ±2℃(0‑100℃ in central zone). Refreshing rate is 8HZ, no calibration required. Emissivity is adjustable from 0.1 to 0.99.
3、SPI CHIPS Embedded SPI flash memory chips that view and copy image files by connecting a computer or mobile phone to a data line. Integrated design, no external equipment required.
4、FR4 EPOXY BOARD SHELL: Infrared imaging device uses printed circuit board, FR4 epoxy board shell for better protection of internal components. USB charging, battery life is up to 4 hours, can be used while charging.
5、WIDE USES The IR thermal imager can be used in many occasion and is an essential tool for household and industrial use. Suitable for industrial parts temperature monitoring, floor heating equipment leakage and maintenance.
Item Type: Thermal Imager
Material: FR4 Epoxy Board, Printed Circuit Board, ABS
Weight: Approx. 106g / 3.7oz
Product Size: Approx. 5.5x8.5x2cm / 2.2x3.3x0.8in
Resolution: 32x24
Model: JM_MLX90640
Sensor: Using MLX90640ESF-BAB infrared thermal imaging sensor
Temperature Measurement Range: -40℃ -300℃
Measurement Accuracy: +/-2℃ (central area, 0-100℃)
Working Temperature: 10℃ -50℃
Working Humidity: < = 70%
Refreshing Rate: 8HZ
Sensor Field Of View: 55° x35°
Emissivity: 0.1-0.99 Adjustable
Display: Center Point, Maximum and Minimum Temperature
Battery: 1500mAh Lithium Ion Battery (Shipped With Built In Battery)
Power Socket: Micro USB
Uses: High accuracy non contact temperature measurement, security and intrusion detection, body temperature detection, intelligent building environment temperature measurement and control, automotive air conditioning control, microwave oven and oven temperature detection and control, temperature monitoring of industrial parts, apparent temperature sensors, floor heating equipment Side leakage and maintenance, thermal detection of circuit boards and components
1 x Thermal Imager
1 x USB Cable
1 x Manual
1 x Hanging Rope
Features
- BrandSTUNACY
- Battery life4 h
- ConnectivityUSB
- ManoMano ReferenceME211702616
- MMID905064181770
