Kit of 500 insulated and waterproof electrical wire lugs, heat-shrinkable butt connectors for automotive and marine applications

Product Description:

Function:

Temperature Specification

Minimum Melting Temperature: 138°C

Minimum Compressing Temperature: 80°C

Working Temperature: -55°C to 125°C

Compression Temperature > 160°C

Material: PE, Welded

Product Name: Welded hot can be performed

Maximum voltage: 600V

Polyene material

Recovery: 2:1

Dielectric strength: 1kW

Protection level: IP67

Includes:

200 x red heat-shrink connectors

180 x blue heat-shrink connectors

80 x white heat-shrink connectors

40 x yellow heat-shrink connectors

Features:

Designed with a polyacrylic tube exterior and The interior, coated with thermal adhesive, creates a durable, watertight seal between the wires and connectors.

●Watend connectors will prevent corrosion even in the most humid environments.

Features:

● The transparent sleeve of the butt connector allows for visual inspection. --- You can control the working temperature and heating time.

●Easy identification: different colors for different connector sizes

● Can be perfectly used in marine and automotive applications.

Feature:

●Sealed connectors allow you to use them in hard-to-reach environments or confined spaces. Since no setup is required, you simply place the bare wire into the solder sleeve and apply heat to complete the connection. Simple connection, insulation, and sealing in a single step of the wire.

Feature:

● Insulation protection: used to seal threaded fittings, prevent electrical leakage, and stop rodents from interfering with circuits.

● When the soldering ring is heated, the bottom melts and flows into the wire connection, effectively preventing the connection from breaking.

How to use:

1. Push the wire through the connector tube to the end of the correct size, get the connection and wire handling right, and move the connector so that the solder ring portion is aligned with the wire connection;

2. Use a heat gun to seal the ends of the tube so they shrink. The sealing ring, when heated, becomes a watertight ring;

3. Heat the solder ring with a heat gun until the ring forms and fits into the wire connection;

WARNING: Heat the section of the heating conduit until it is close to constricting around the wire; Excessive heating will completely melt the heating element. The solder ring must be thoroughly heated to access the wire connection.

Package Included:

Set of Solder Rings * 1

Main Points:

1. The product size is measured manually; there may be errors.

2. Since different monitors display colors differently, please refer to the actual color you received.

3. Please confirm the size before purchasing.
