kWh meter, 2-wire electronic electricity meter, single-phase electricity meter, DIN rail electricity meter, for home use (20(80) A)
Sold by AINSCO
You may also like
Compare with similar items
Product information
Description
General Description
The kWh meter is a 2-wire electronic electricity meter, designed for installation on a standard 35 mm DIN rail. It is ideal for measuring energy consumption in homes and small premises. This model complies with safety and performance standards, ensuring reliable and secure operation.Technical Specifications
- Model: XTM75S-U
- Accuracy: Class 1
- Voltage: 220 V
- Current: 5(30) A, 15(60) A, 20(80) A (optional)
- Insulation Performance: AC voltage 4 kV for 1 minute, pulse voltage 1.2/50 µs waveform 6 kV
- Size: 10 x 7.6 cm (3.94 x 2.99 in)
- Weight: Approx. 270-277 g
Compatibility and Accessories
- Installation on standard 35 mm DIN rail
- Standard Configuration with a passive pulse output port (polarity)
- Option to select a remote passive pulse output port (non-polarity)
Installation
The meter is easily installed on a standard 35 mm DIN rail, allowing for simple integration into electrical panels.Application
This meter is designed to measure single-phase, two-wire active energy consumption. It features a 5+1 digit LCD display (99999.1 kWh) and allows for automatic detection of the charging current flow direction.Other Information
- Complies with DIN EN 50022
- Complies with JB/T7121-1993
- Complies with IEC 62053-31
- Complies with IEC 62053-21
- Standard short terminal cover; an extension terminal cover is available for safe operation.
Features
- BrandSANS MARQUE
- Length10 cm
- Width10 cm
- Height10 cm
- Weight1000 g
