LCD Energy Meter KWH 7 Digits 3x20 (80) A 3x230 / 400V 50Hz Three-Phase Four-Wire Din Rail KWH Watt Hour Din Rail

General description Seven-digit LCD display with a 6+1 digit format, capable of showing up to 999999.1 kWh. This energy meter is designed for three-phase four-wire systems, providing accurate measurement of active power consumption. Technical specifications Display: 7 digits (6+1 digit display) Maximum measurement: 999999.1 kWh Power supply: 3x230/400V Frequency: 50Hz Current rating: 3x20 (80) A Other information Standard configuration includes a short terminal cover; an optional extended terminal cover is available for enhanced safety. Features one closed passive pulse output polar port and one non-polar pulse output far passive port. Equipped with 5 LEDs indicating power status, closed energy signal pulse, remote energy pulse, and data communication status. Measures three-phase four-wire active power consumption independently of load current direction.
