Mini Split Air Conditioning Condensate Pump, Automatic Drainage, Silent Device S1 AC110-240V

1. The mini split condensate pump is safe and stable, highly efficient and energy-saving, with low noise.
2. Adopting new probe induction technology, automatic drainage, replacing the original float induction, avoids abnormal drainage caused by float movement and loss of magnetic force.
3. The automatic condensate pump adopts a wide voltage design of 100-220V, 3W power, energy saving and environmentally friendly, very quiet during operation, less than 18 decibels, suitable for any indoor environment.
4. Made of engineering plastic, professionally designed mini split automatic condensate drain pump.
5. Suitable for HVAC, air conditioners, dehumidifiers, furniture, ice machines, and other equipment requiring automatic drainage pumps.

Specification:

Item Type: Condensate Pump.
Model: S1
Material: Engineering Plastic
Purpose: Air Conditioning Pump
Scope of Application: Professionally designed mini automatic condensate drain pump, suitable for HVAC, air conditioners, dehumidifiers, furniture, ice machines, and other equipment requiring an automatic drain pump.
Voltage: 110-240V 50-60HZ
Power: 3W
Maximum Recommended Head: Approx. 10 meters / 32.8 feet
Maximum flow rate: 24 m³/h
Maximum cooling capacity of applicable air conditioner: 30,000 BTU/h (less than 3 HP)
Water storage tank capacity: 50 ml
Noise at 1 meter: 19 dB(A)
Drive mode: Electric
Performance: Automatic
Delivery medium: Clean water pump
Installation method: Wall-mounted
Operating temperature: 0-50°C

Package list:

1 x Drain pump

1 x Connector

2 x Water hoses

2 x Loops

1 x Elbow

1 x Air hose

1 x Assembly anti-siphon

1 adapter

7 cable ties

1 nut

1 user manual

Note:

1. The air conditioning drain pump is only suitable for condensate water from the air conditioning unit, not for other corrosive liquids. 2. The air conditioning drain pump cannot be used as a submersible pump immersed in water, otherwise an electric shock may occur. 3. When installing or adjusting the air conditioning drain pump, ensure that the drain pump is not connected to the power supply. 4. Installation and maintenance of the air conditioning drain pump should be carried out by professionals to avoid any danger. 5. Please use the air conditioning drain pump in an indoor environment. Do not use the equipment in an oil mist environment, especially in a dusty environment. 6. Proper use and maintenance can extend the product's lifespan. It is recommended to check and clean the air conditioning drain pump before seasonal changes and again the following year. 7. Please install a dedicated power cord for the air conditioning drain pump to ensure a continuous power supply. 8. Please select an air conditioner drain pump with an appropriate pumping speed based on the air conditioner's cooling capacity. Otherwise, the air conditioner drain pump may not be able to drain the water in time and could overflow due to excessive water consumption over a short period. Furthermore, frequent starting and continuous motor operation may also occur.This can cause overheating and malfunction. 9. A relay is integrated into the air conditioning drain pump. Once the warning water level is exceeded, it will activate and cut off power to the air conditioning unit. In this case, please turn off the air conditioner immediately, take photos, and have it inspected and repaired by professionals.
