Name: 48GTG Gas Test Gauge 120mb 1200mm (48in)
Brand: MONUMENT
SKU: 48GTG
Availability: OutOfStock

Product information

Description

General description

The Monument MON48GTG 48Gtg Gas Test Gauge is a durable plastic tool designed for testing pipework installations for leaks using air before introducing gas. It is also used for checking and setting correct gas pressures on domestic and commercial appliances. The gauge features an extruded cover that can be clipped over the base for vertical standing during use, and a hanging tab for hanging from suitable protrusions.

Technical specifications

Capacity: 120 mb (millibars)

Size: 1200 mm (48 inches)

Measurement method: Plastic U-tube

Compatibility and accessories

Designed for testing pipework and appliances requiring pressure measurement in gas and air systems. No specific accessories mentioned; compatible with standard pressure testing setups.

Installation

The gauge can be clipped over the base for vertical positioning during testing.

The extruded cover slides off for maintenance or storage.

The hanging tab allows hanging from suitable protrusions for hands-free operation.

Usage

Use the gauge to test pipework installations for leaks with air before gas is introduced.

Check and set correct gas pressures on appliances by attaching the gauge to the system.

Adjust the scale for zeroing water level as needed for accurate readings.

Features

Brand
MONUMENT
NF certification
NF120
Warranty
1 year(s)
Width
2.5 cm
Capillary length
120 cm

48GTG Gas Test Gauge 120mb 1200mm (48in)
