MT-30 Black Manual Labeling Machine for Round Bottles 0.79in-4.72in Diameter 10-30pcs/min Speed High Accuracy ±0.5mm for Cosmetic Beverage Food Industries

~~£89.99~~

£1Offered

To be applied on the payment page

Offer valid today only.

Sold by DENCRESTUK

Product information

Description

General description

This MT-30 Black Manual Labeling Machine is designed for labeling round bottles with a diameter ranging from 0.79 inches to 4.72 inches. It operates at a speed of 10-30 pieces per minute, providing high accuracy of ±0.5mm, making it ideal for various industries including cosmetics, beverages, and food. The machine is made of durable iron and features a high-temperature paint baking process, ensuring longevity and resistance to deformation.

Technical specifications

Model: MT-30

Color: Black

Material: Iron

Style: Modern

Process: High-temperature Baking Paint Process

Mounting Type: Desktop Mount, Freestanding

Accuracy: ±0.5mm/0.01inch

Suitable Bottle Diameter: 15-120mm/0.5-4.7inch

Label Speed: 10-30pcs/min

Label Roll Inner Diameter: ≥75mm/2.9inch

Label Roll Outer Diameter: ≤250mm/9.8inch

Label Width: 10-110mm/0.3-4.3inch

Label Length: 10-300mm/0.3-11inch

Net Weight: 5kg/11.02lbs

Gross Weight: 5.5kg/12.13lbs

Package Size: 42*25*28cm/16*9.8*11.0inch

Installation

Attach the label cartridge to the side of the machine with screws and nuts.

Attach the nut and the label cartridge with a silicone ring.

Fix the paper supply tray and the middle part with screws.

Insert the paper supply tray into the label cartridge.

Attach the hand joystick to the side of the machine with screws.

Attach the remaining part of the hand joystick.

The installation is complete.

Usage

Use an allen key to unscrew the paper supply tray.

Insert the label into the label roller and reattach the paper supply tray.

Pull out a piece of label paper and insert it into the machine in sequence.

Place the bottle on top of the machine.

Rotate the hand joystick to complete the labeling.

Other information

Package includes: 1 Labeling Machine, 2 Paper Supply Trays, 1 Label Cartridge, 1 Set Hand Joystick, 3 Allen Keys, 1 Silicone Ring, 11 Screws, 2 Label Tray Clamps.

It is recommended to place a piece of tape at the beginning of the label for easier pulling.

Please allow slight color differences due to lighting and a 1-3cm error due to manual measurement.
