Multi-Grip M8 Blind Rivet Nuts, 6pcs Pre-domed Flat Head Threaded Insert Nuts in 304 Stainless Steel Plus Nuts for Industrial Construction
Buying for your business?
Negotiated prices excl. VAT up to -20%
You may also like
Compare with similar items
Product information
Description
Material: 304 Stainless Steel; Performance Class: 4.8; Thread Diameter: M8; Pitch: 1.25 mm; Overall Length: 30.5 mm / 1.2"; Head Size: 19 x 1.6 mm / 0.75" x 0.06" (D*T); Shank Diameter (Drill Hole Size): 11 mm / 0.43"; Length after riveting: 14.3 mm / 0.56"; Riveting plate thickness: 1-7 mm / 0.04"-0.28"; Package contents: 6 pcs x Rivet Nuts
Material: The Multi-Grip rivet nut is made of 304 stainless steel, with a smooth surface, high hardness, corrosion resistance, and durability.
Easy to use: Drill a suitable hole according to the size, then insert the expansion nut with a tool to pull the bolt so that it expands and bonds firmly to the substrate. The enlarged head of the nut is larger and can be securely fastened to the plate, providing good load-bearing capacity.
Application: Rivet nuts can be securely fastened to thin sheet metal to provide a tight screw locking force, such as sheet metal or non-metallic materials, plastics, etc. wood, etc. Widely used in industry, construction, furniture, household appliances, equipment, etc.
Specifications: Material: 304 Stainless Steel Performance Class: 4.8 Thread Diameter: M8 Pitch: 1.25 mm Overall Length: 30.5 mm / 1.2" Head Size: 19 x 1.6 mm / 0.75" x 0.06" (D*T) Shank Diameter (Drill Hole Size): 11 mm / 0.43" Length After Riveting: 14.3 mm / 0.56" Rivet Plate Thickness: 1-7 mm / 0.04"-0.28"
Package Contents: 6pcs x Rivet Nuts
Features
- BrandOTHERS
- MaterialStainless steel
- Pcs per pack1
- Common resistance classes4.8
- Nominal diameter8 mm
- Metric thread not standard threadM8
- ShapeCylindrical
- Nut typeCylindrical
- ManoMano ReferenceME223293078
- MMID860395467510
- Product code6953625646235
- EAN6953625646235
