[NEVER USED] 12V LED power supply, LED transformer IP44 low voltage LED adapter driver for Christmas light, string lights
You may also like
Compare with similar items
Product information
Description
Product never used, packaging damaged during transport. Unopened product, repackaged in our warehouses, in perfect working condition, warranty available.
Input: 100-240V AC, 50-60Hz; Output: 12V DC, rated power 12W.
Wide Application: The 12V 12W 1A LED adapter is suitable for low voltage LED lights, such as Christmas tree lights, string lights, spotlights, lawn lights, curtain lights, holiday lights, etc.
Warm Reminder: Please check the voltage, current, wattage, etc (+/-) two connection holes for your device before purchasing.
IP44 WATERPROOF: This IP44 rainproof low voltage adapter features continuous operation and can be used indoors and outdoors.
1. Reliability
Temperature rise (burn-in): 85% to 95% load per unit, 40+/-5 degrees, 4 hours
Leakage current: 0.25 mA, max. 240 VAC
Dielectric withstand voltage (between primary and secondary voltages), 3000 VAC, 60 s, 5 mA max.
MTBF: per MIL-HDBK-217F, full load, 25 degrees, 50,000+ hours
2. Protection Function
Short-circuit protection: The switching power supply can resume normal operation when the short circuit is eliminated.
Overcurrent protection: Once the fault overcurrent is eliminated, the switching power supply will automatically resume normal operation.
Overvoltage protection: When the output voltage of the switching power supply exceeds 150% to 180% of the rated voltage, the switching power supply enters the protection state and can resume normal operation after the fault is eliminated.
3. Environment
Operating temperature: 0–40 degrees under full load conditions.
Storage temperature: -20–85 degrees.
Humidity: 5% at 95% non-condensing.
Features
- BrandODIPIE
- Power12 W
- Output voltage12 V
- Power supply destinationLight fitting
- IP ratingIP44
