[NEVER USED] 2pcs 12V Temperature Controller Module, Digital Display Thermostat Module with Waterproof NTC Probe -50 110℃, Electronic Temperature Control Module Switch

Product never used, packaging damaged during transport. Unopened product, repackaged in our warehouses, in perfect working condition, warranty available.

The thermostat module controller has inputs for sensors, buttons, LED indicators, and relays. It can be reprogrammed for control, timing, or counting.

Temperature measuring range: -50–110°C. Control accuracy: 0.1°C. Input power (DC): 12V; Measuring input: NTC (10K 0.5%); Waterproof sensor: 0.5 m; Output: 1 relay output, capacity: 10A; Power consumption: Quiescent current: 35 mA; Current: 65 mA.

Electronic digital thermostat with a 3-bit red LED display and high brightness. Heating and cooling operation for easy control of appliances and devices.

The output is electronically controlled by a microprocessor, guaranteeing the highest intervention precision and excellent resolution of the measured temperature.

The NTC probe is waterproof and allows the temperature to be controlled even in liquids, thus enabling controlled heating or cooling.

Specifications:

Dimensions: 48.5*40*15.8 mm

Temperature control mode: ON/OFF

Temperature range: -50–110 degrees

Resolution: When the temperature is 0.1°C, the resolution is -9.9~99.9; the other temperature segment is 1°C. Control accuracy: 0.1℃

Hysteresis accuracy: 0.1℃

Update rate: 0.5 s

High temperature protection Supply voltage: DC 12V

Static current: less than 35 mA, pull current less than 65 mA

Output voltage: DC 12V

Output power: 20A relay

Measurement input: NTC (10K 0.5%) waterproof sensor

Environmental requirements: -10-60 ℃; Humidity: 20 to 85%

Instructions for use:

Plug in the power adapter and the device, the measurement temperature will be displayed,

Press the "Adjust" button. " button, press "+" or - " to set the desired temperature (press "+" or - " to quickly increase or decrease).

Press "SET" to confirm the setting and return, the controller automatically performs an on/off relay.

The thermostat output is a 10A relay, which responds to a variety of high-performance LED indicators: LED off indicates that the relay is off, and that the relay is closed. Tubes: "LL" indicates that the sensor is open, "HH" indicates that the relay is out of range, the relay is forcibly disconnected. "--" indicates high temperature alarm. Long press the "SET" button. To enter the main menu settings, press "+" or "-" to switch between P0 and P6, then long press "SET" or press and hold for 10 seconds without pressing any buttons to confirm the setting and return.

Return to factory settings ----- Hold down the "+" and "-" buttons when turning off. "888" will be displayed when turning on to restore the factory settings.

Package includes:

2 12V DC digital temperature control boards for PC
