One Way Non Return Inline Check Valve For Fuel Gas Liquid Air( 1/8")

1、This check valve allow the liquid or air to flow in only one direction, thus preventing backward flow.

2、Features good high temperature resistance and corrosion resistance

3、Widely used in many industry applications including fuel pumps, engines, household appliances, medical devices, agriculture equipment, beverage machinery, ink supply systems, etc.

4、 The material for this check value can endure fuel/oil, acid, alkaline solutions.

5、This one way check valve is convenient for replacing the broken one

Features:

This check valve allow the liquid or air to flow in only one direction, thus preventing backward flow.

Features good high temperature resistance and corrosion resistance

Widely used in many industry applications including fuel pumps, engines, household appliances, medical devices, agriculture equipment, beverage machinery, ink supply systems, etc.

The material for this check value can endure fuel/oil, acid, alkaline solutions.

This one way check valve is convenient for replacing the broken one

Specification:

Body material: PA66

Sealing material: VITON

Spring material:SUS316L

Connection form: quick install

Type: 1/8", 3/16",1/4",5/16"(Optional)

Structure: one-way valve

Applicable medium: oil

Form: spring type

Pressure environment: normal pressure

Flow direction: one-way

Driving mode: servo

Working temperature: high temperature

Spring one-way valve opening pressure :1~2Kpa

Weight: Approx.4g~5g/0.1oz~0.2oz

Body material:

Nylon 66 (PA66) : translucent or opaque milk white crystalline polymer, malleable, melting point 252℃. Brittle temperature 30℃. The thermal decomposition temperature greater than 350℃. Continuous heat 80-120℃. It is resistant to acid, alkali, most inorganic salt aqueous solutions, halogenated alkanes, hydrocarbons, esters, ketones and other corrosion, but soluble in phenol, formic acid and other polar solvents. Excellent wear resistance, self - lubricating, high mechanical strength.

Sealing material:

Fluorinated rubber (VITON) : with high temperature resistance, oil resistance and resistance to a variety of chemical corrosion characteristics, fluorinated rubber has a high degree of chemical stability, is the elastomer in the medium resistance of the best one. Fluorine rubber has excellent anti - aging and ozone resistance. Fluorine rubber has a high solubility to gas, but a low diffusion speed, so it has a low air permeability

Spring material:

SUS316L stainless steel: SUS316L stainless steel is an acid resistant, corrosion resistant alloy material, it has high temperature resistance, easy to process, high strength and so on

Package list:

1 x Inline Check Valve
