PD60 Fuel Injection Ignition Simulator, ECU Maintenance Platform, Testing Equipment for Petrol Vehicle Computer Board and Derv.

Features: 1. Injector Simulation Function: Supports simulation of 12-24V electromagnetic fuel injectors and 12V gasoline injectors. 2. Ignition Coil Simulation Function: Supports simulation of positive-trigger and negative-trigger ignition coils. 3. Display Function: Built-in real-time display computer module with voltmeter and ammeter functions, monitors voltage and current in real time during the fuel injection and ignition processes, helping technicians to pinpoint problems more accurately. 4. Rich Functionality: Includes overcurrent protection circuit, built-in diagnostic port, high-power resistor (for simulating fuel metering valves), and 120Ω terminal resistor. 5. With CAN data acquisition port: The PD60 is equipped with a CAN analyzer port and a connection cable, which can easily acquire, analyze, store, and read CAN bus data (telegrams), making it very convenient to use. 6. Note: This product does not include a signal generator and cannot simulate sensor signals. Specifications: The PD60 fuel injection ignition simulator is a comprehensive tool for repairing and testing car computers. It can simulate not only gasoline and fuel injectors but also ignition coils, making it ideal for car computer repair and testing. It is a very practical tool for repairing and testing car computers, significantly improving the efficiency of automotive repair shops. It monitors voltage and current in real time during the fuel injection and ignition process, helping the repair technician to pinpoint the problem more accurately. Extensive features: Equipped with overcurrent protection circuitry, integrated diagnostic port, high-power resistor (for simulating fuel metering valves), and a 120 Ω terminal resistor. CAN data acquisition port: The PD60 is equipped with a CAN analyzer port and connection cable, enabling easy acquisition, analysis, storage, and playback of CAN bus data (telegrams), making it very convenient to use. Note: This product does not include a signal generator and cannot simulate sensor signals. Specifications: Name: Ignition Simulator Material: Plastics + Metal Item Size: 180 * 130 * 45.5 mm / 7.09 * 5.12 * 1.79 inches Package Size: 250 * 200 * 150 mm / 9.84 * 7.87 * 5.91 inches Package Weight: 500 g / 1.10 lb Packing List: 1 * Ignition Simulator 1 * Power Cable 1 * High Power Resistor 1 * CAN Cable 3 * Computer Connection Cables 1 * Flat Cable 9 * Wiring Plugs
