PH Probe, High Precision Replacement Probe, PH0-14 Detection Concentration Range, Simple Calibration, Wide Application MUMU

~~£30.83~~

Of which environmental contribution £0.01 including VAT.

Buying for your business?

Negotiated prices excl. VAT up to -20%

Create a pro account

Sold by Permu UK

Product information

Description

General description

The PH Probe is a high precision replacement probe designed for accurate pH detection in a range of 0-14. It features simple calibration and is suitable for various applications, ensuring reliable performance in diverse environments.

Technical specifications

Heating voltage: 5±0.2V (AC/DC)

Working current: 5-10mA

Detectable concentration range: pH 0-14

Detection temperature range: 0-80℃

Response time: ≤5S

Settling time: ≤60S

Component power: 0.5W

Operating temperature: -10 to 50°C (rated temperature 20°C)

Humidity: 95% RH (rated humidity 65% RH)

Module size: 42 mm × 32 mm × 20 mm

Output: Analog voltage signal output

Mounting: 4 M3 mounting holes

Usage

Remove the protective cover of the electrode before testing. The solution in the cover is 3MKCL; if crystals appear, it is normal and will not affect the electrode's use.

Ensure the sensitive bladder is completely filled with liquid. If bubbles are present, gently shake the electrode to remove them.

Connect the PH electrode to the input terminal of the PH instrument and perform calibration according to the instrument's manual.

Other information

For storage, clean the electrode with distilled water and place it in a protective bottle. Activate it by injecting the solution before the next test.

If not used for a long time, rinse the electrode and absorb any remaining distilled water.

Avoid contact of the sensitive glass bulb with hard objects to prevent damage.

To rejuvenate the electrode, immerse the measuring end in 4% HF for 3-5 seconds or dilute HCL solution for 1-2 minutes, then clean with distilled water.

For contamination issues, clean with a suitable solution to restore performance.

Features

Brand
YMYNY
Total length
42 mm
Material
Plastic
Measured parameters
PH
Voltage
5 V
ManoMano Reference
ME93611825
MMID
536486664304
Product code
XHWD-M-XXW-7034
EAN
6941454630808
