Portable Pneumatic Air Riveter Hydraulic Pop Rivet Gun Riveting Tool 4Nozzles

Description

Are you tired of manual rivet tools due to their arduous task and extended working time? Say goodbye to such mundane struggles and upgrade to the efficient and labor-saving air pneumatic rivet gun. It's air-powered and has powerful accessories, which efficiently saves you valuable time and effort, making your riveting process faster. With this powerful and stylish device, you can rivet more efficiently and smoothly.

Key Features

Strong and Durable: Made of premium cast iron, aluminum with a quenching process, it has high hardness and precision, ensuring a long service life.

High Efficiency: The pneumatic design can generate strong power with 0.6-0.8Mpa working pressure, and the 866.8 Kgf pulling pressure can help you work with high efficiency, saving time and effort.

Thoughtful Design: The silenced exhaust can effectively reduce noise. The standard air inlet (1/2" NPT) makes this product suitable for most air compressors.

Powerful Kit: It is equipped with 4 different sized guide nozzles (0.09inch, 0.13inch,0.16inch, 0.19inch) that are hardened and quenched to ensure stable tension output., meeting your different rivet needs.

Easy to Use: The pneumatic riveting machine has a quick release valve that allows the quick cylinder to return to high-speed assembly operation. The rivet collection bottle can automatically collect used rivets to keep the workbench clean and facilitate recycling.

Compact and Portable: It's lightweight(3.26lb) and compact size(3.94*10.83in), allowing for easy carrying and storage in your workshop. It is an ideal rivet tool for professionals and DIY enthusiasts.

Quality Service: We stand behind all our guests and look forward to assisting you with your purchase. It is our pleasure to answer your confusion and questions. The end of the story between us is not "we sell and you buy".

Details

Comfortable Handle: The ergonomic handle has a comfortable grip and reduces your hand fatigue. It is very convenient to operate even for women.

Shockproof Rubber Pad: Made of high-quality rubber, it is wear-resistant and durable, and it can prevent shock and fall.

Smooth Edge: The whole product's edge is very smooth and without any sharp corners, making it very safe to use.

Application

It can be widely used in aluminum ladder industry, luggage industry, door and window industry, computer chassis, aviation equipment, automobile manufacturing, shipbuilding, decoration industry, container production, electronic manufacturing, and mechanical manufacturing industries etc.

How to Use

• Connect the air pipe connector.
• Place the core pulling nail into the guide nozzle.
• Place the core pulling nail into the workpiece.
• Align and buckle the riveted workpiece.
• Riveting is completed.

How to Add Pneumatic Oil

• Remove its base.
• Clamp the hex nut and carefully pull out the chassis.
• Fill the small hole with pneumatic oil(not included).
• It is best to inject pneumatic oil into the central circular hole through a conduit(not included).

How to Replace the Rivet Gun Claw Piece

• Loosen counterclockwise.
• Remove the guide nozzle.
• Tighten clockwise.
• Loosen the outer sleeve counterclockwise.
• Clamp the sleeve with a wrench and loosen the claw sleeve counterclockwise.
• Remove the claw piece and complete the replacement.

Specification

Model: KD-903

Color: Black+Green+ Silver

Interface: UK

Material: Cast Iron, Aluminum, Rubber,

Process: Quenching

Power Source: Air-powered

Applicable Rivets: Aluminum/Iron Rivets

Working Stroke: 14mm/0.55in

Riveter Type: Rivet Gun

Working Pressure: 0.6-0.8Mpa

Nozzle Size: 2.4mm/0.09inch, 3.2mm/0.13inch, 4mm/0.16inch, 4.8mm/0.19inch

Applicable Hose Diameter: 10mm/0.39in

Air Inlet Thread: 1/2" NPT

Pulling Pressure: 8500N/866.8 Kgf

Switch Trigger Length: 90mm/3.54in

Spear Length: 165mm/6.5in

Product Size(D*H): 100*275mm/3.94*10.83in

Package Size: 31*12*16cm/12*4.7*6in

Item Weight: 1.48kg/3.26lb

Gross Weight: 1.55kg/3.4lb

Package Included

1* Air Pneumatic Rivet Gun

4* Guide Nozzles (One is Already Installed)

1* Rivet Collection Bottle

1* English Instruction

Other Accessories for Assembly

Notes

• This product is not suitable for stainless steel rivets.
• Please check compatibility before purchasing.
• If you need to pull nails of different specifications, please remember to change the guide nozzle according to the size of the rivets, otherwise it is easy to get stuck. When a rivet is placed into the guide nozzle, there must be a certain gap. When it is pulled apart, the cutting section will deform and widen, so it cannot be placed just right, otherwise the nail will get stuck.
• As the frequency of use increases, the spindle will wear out. Please be careful and replace it if necessary.
• Please do not disassemble this product by yourself.
• Please allow the slight color difference caused by the shooting light and 1-3 cm error due to manual measurement, and make sure you do not mind before ordering.
