Portable radiation monitor 0.01 μSv/h 50 mSv/h 1800 mAh 2.4-inch TFT LCD monitor Portable X-ray γ β radiation detector

General Description

The portable radiation monitor is a compact and efficient device designed to measure radiation levels, including X-rays, gamma rays, and beta rays. It is equipped with a 2.4-inch TFT LCD screen and a glass Geiger counter tube, offering high accuracy and sensitivity. This device is ideal for use in various environments, such as nuclear laboratories, nuclear power plants, and for monitoring personal radiation doses.

Technical Specifications

• Weight: 321 g
• Material: ABS
• Detector: Glass Geiger counter
• Display: 2.4-inch TFT LCD
• Dose Rate Measurement Range: 0.01 μSv/h - 50 mSv/h
• Dose Measurement Range: 0 μSv - 1000 Sv
• Sensitivity: > 1 cps/μSv/h (relative to 60Co)
• Energy Response: 48 keV - 1.5 MeV
• Relative Error: Not specified
• Power Consumption: < 15 mW (long life mode, lifespan ≥ 30 days)
• Operating temperature: -10°C to +45°C
• Product size: 127 x 65 x 27 mm
• Battery: Lithium 3.7 V, 1800 mAh

Operation

• To turn on the device, press and hold the power button for 3 seconds.
• It provides real-time dose rate measurements, as well as audible and visual alarms when radiation thresholds are reached.
• The alarm threshold is adjustable and can be set according to the user's needs.
• It is recommended to check the dose rate after accidentally dropping the device.
• In case of a blockage alarm, immediately leave the high-radiation area intensity.

Other information

• The product includes: 1 x instructions, 1 x USB cable, 1 x host.
• External Type-C interface for power or connection to a PC-based radiation dose management system.
• Built-in memory function to retain data even after a power outage.
• Multilingual menu and alarm options (sound, flashing light, vibration) offer flexible operation.
