Vand Olieborepumpe, Elektrisk Borebit Brændselsolie dieselpumpe, selvpring olieborefitings fittings-

~~£24.51~~

Product information

Description

General description

The electric borehole oil pump is designed for efficient fuel transfer, made from durable ABS and aluminum materials. It features high hardness and a good seal, ensuring reliable performance in various applications.

Technical specifications

Material: ABS and aluminum

Operating temperature: 5 to 49 degrees Celsius

Flow rate at 1500 rpm: 15 L/min

Flow rate at 3000 rpm: 30 L/min

Recommended speed: between 1500 and 3500 rpm

Maximum hose length: 2.75 meters (9 feet)

Installation

Ensure the oil pump inlet tube is sealed before use.

Install a sealing ring at the interface to prevent leakage.

Check that the air in the oil pump is emptied before use.

Usage

After starting, check if the liquid is being sucked into the pump within 20 seconds.

If not, verify the correct installation of the oil inlet pipe.

Do not let the pump run dry; check for hose blockages or breaks if it does not start.

The pump can also be used as a water pump for swimming pools, aquariums, fountains, and household cleaning.

Other information

It is recommended to add a filter to the inlet line when pumping abrasives or liquids containing solids for longer pump life.

The compact design makes it easy to carry and set up at your desired workplace.

Features

Brand
TUMALAGIA
Warranty
2 year(s)
Self-priming
Yes
Max. flow rate
30 l/min
Material
Acrylonitrile butadiene styrene (ABS)
