Rawlplug Rawlbolt® Loose Bolt M6/10L - Pack of 5 (Model RAWM610LB)

Description

The Rawlplug Rawlbolt® Loose Bolt M6/10L is a versatile anchor suitable for use in cracked and non-cracked concrete, hollowcore slabs, flooring blocks, and ceramics. It is recommended for applications requiring fire resistance. The bolt features a three-piece expanding sleeve that provides maximum expansion for optimal load capacity and safety in various substrates. This product is the loose bolt version of the popular all-purpose expanding shield anchor.

Technical Specifications

• Anchor Diameter: 6mm
• External Diameter: 12mm
• Length: 55mm
• Fixture Max. Thickness: 10mm
• Hole Diameter: 6.5mm
• Hole Diameter in Substrate: 12mm
• Installation Torque: 6.5 Nm
• Wrench Size: 10
• Minimum Hole Depth in Substrate: 50mm
• Minimum Installation Depth: 45mm
• Minimum Substrate Thickness: 100mm
• Minimum Spacing: 35mm
• Minimum Edge Distance: 53mm

Compatibility and Accessories

• Compatible with cracked and non-cracked concrete, hollowcore slabs, flooring blocks, and ceramics.
• Designed to work with a three-piece expanding sleeve for maximum expansion and load capacity.

Installation

• Drill a hole of 6.5mm diameter to a minimum depth of 50mm in the substrate.
• Insert the bolt into the hole and tighten to the recommended torque of 6.5 Nm using a wrench size 10.
• Ensure proper spacing of at least 35mm between anchors and at least 53mm from edges.

Usage

• Use in concrete, hollowcore slabs, flooring blocks, and ceramics.
• Suitable for applications requiring fire resistance and high load capacity.

Other Information

• Pack Quantity: Bag of 5 bolts.
• Product MPN: R-S1-RBL-M6/10/5
• EAN: 5906675094366
