Recoil RCL05054 Free-Run Metric M5.0x0.80 Pitch Inserts, 2.0D Diameter

Description

• Recoil inserts are made from high-quality stainless steel wire with a diamond-shaped cross section, designed to reinforce or repair threaded holes.
• They are wound to match a spring thread shape and are larger in diameter than the tapped hole.
• During installation, the insert is compressed into the hole and then springs back to anchor securely, providing a durable and stronger thread.

Technical Specifications

• Material: Stainless steel
• Shape: Diamond-shaped cross section
• Size: M5.0 x 0.80 pitch
• Length: 2 times the diameter

Compatibility and Accessories

• Designed for use in tapped holes requiring reinforcement or repair
• Compatible with standard M5.0 x 0.80 pitch threads

Installation

• Insert the recoil into the pre-tapped hole
• Compress the insert during installation
• Allow it to spring back, anchoring securely in the hole

Usage

• Reinforces damaged or worn threads
• Provides a stronger, more durable threaded hole
• Suitable for applications requiring repeated assembly and disassembly
