RJ45 to 8 RS485 Hub Converter TVS Surge Protection 115200BPS Hub Board for Security Monitoring DC7‑30V Hub Module

1、SURGE PROTECTION: This hub module has TVS surge protection to prevent sudden high currents and increase safety.

2、ADJUSTABLE BAUD RATE: The default baud rate of the module is 115200BPS, which can be set via WEB to 1200, 2400, 4800, 9600, 19200, 38400, 57600 115200 and 230400BPS.

3、POWERFUL FUNCTIONS: The parity bits of the RJ45 to 8 RS485 hub module can be no parity, even parity and odd parity.

4、WIDE COMPATIBILITY: The module supports all RS485 devices for eletechsup, such as 10IOA08, R4DCB08, R4D3B16, N4D3E16, N4AIA04.

5、VARIOUS APPLICATION: The module is suitable for smart home, home automation, security monitoring and identification system.Item Type: RJ45 to 8 RS485 Hub Converter

Material: PCB

Operating Voltage: DC 12V, 24V (DC 7-30V)

Operating Current: 18-25mA

Installation: DIN35 and C45 rail

Operating Modes: For UDP, TCP, TCP to RTU, MQTT, HTTP

1 x RJ45 to 8 RS485 Hub Converter
