Product information

Description

General description

This kit of tools is made of superior quality metal and zinc alloy, ensuring high precision and ease of use. It serves as a reliable helper in various production tasks, featuring a simple structure that is easy to maintain. The high sensitivity of the tools guarantees stable and reliable accuracy, making it ideal for measuring precision workpieces.

Technical specifications

Material: Metal + Zinc Alloy

Main Color: Silver + Red

Indicator Accuracy: 0.01 mm

Measuring Range: 0-10 mm / 0-0.4 in

Dial Diameter: 54 mm / 2.1 in

Weight: 140 g / 4.9 oz

Clamp Opening Diameter: 8 mm / 0.3 in

Total Height of Magnetic Base: 195 mm / 7.7 in

Shaft Length: 155 mm / 6.1 in

Base Size: 36 x 35 x 30 mm / 1.4 x 1.4 x 1.2 in

Package Size: 270 x 100 x 80 mm / 10.6 x 3.9 x 3.1 in

Package Weight: 537 g / 1.2 lb

Compatibility and accessories

Can be used with the comparator lever and the small correction counter.

Includes 1 x 0.01 mm Dial Indicator Precision Dial

Includes 1 x Universal Magnetic Base Mount

Usage

Used for measuring shaft runout, shaft thrust, and gear backlash.

Widely applicable in machining, measuring parts, and calibrating equipment.

Other information

Powerful magnetic base with on/off switch for the magnet.

Flexible, strong, precise swivel joints can be adjusted in any direction and to any position.

The V-slot base can be mounted on a cylindrical surface.

Features

Brand
YMYNY
Measurement span
10 mm
Material
Metal
Display mode
Digital
Accuracy
0.01 mm
ManoMano Reference
ME93834639
MMID
895916198922
Product code
XHWD-M-XXW-7707
EAN
6095973116074
