Product information

Description

General description

Perfectly universal shower set compatible with all hot water production systems, including tankless water heaters. The elegant silver finish highlights excellent quality, and thanks to high-quality surface technology, its paint remains shiny. The thermostatic mixer is made of copper, which is antibacterial and anti-corrosive, ensuring a longer service life. The thermostatic valve is set to 38°C, effectively preventing burns, making it especially suitable for children and the elderly. The shower hose is crafted from stainless steel to resist daily corrosion and ensure longevity.

Technical specifications

Pipe Centres: 150mm +/- 10mm

Inlet Connection Size: G1/2" & G3/4"

Minimum Bar Pressure: 0.05 Bar

Maximum Bar Pressure: 0.5 Bar

Tube Diameter: 26mm / 30mm

Shower Hose Length: 1500mm

1st Outlet Flow Rates: 1.0 Bar 3-5L/MIN, 2.0 Bar 6-8L/MIN, 3.0 Bar 9-11L/MIN

Handset / Bottom Outlet Flow Rates: 1.0 Bar 2-4L/MIN, 2.0 Bar 5-7L/MIN, 3.0 Bar 8-10L/MIN

Installation

Installation is straightforward and waterproof. The shower rod is adjustable with a telescopic range of approximately 764-1184mm, allowing for height adjustments. The handheld shower can also be adjusted up and down, but care must be taken to hold down the button during adjustment to avoid damage.

Usage

The thermostatic mixer maintains a precise and stable temperature of 38°C. To adjust the temperature, press and hold the button, with a maximum rotation of 360°. The rain shower head features a 200mm overhead spray with a large shower area and silicone water outlets for easy cleaning.
