Ultrasonic water level sensor, LED display, 4-20mA, tank depth, DC24V 0-5m

Features:

1. Good Performance: This water level sensor embodies the concept of complete digitization and humanization. The digital ultrasonic level features comprehensive functions for measuring and controlling material or liquid levels, data transmission, and human-machine communication.
2. Waterproof ABS Housing: This ultrasonic water tank level sensor is housed in a waterproof ABS engineering plastic casing. The digital ultrasonic level meter's housing is compact and robust, greatly ensuring the instrument's durability.
3. Modular Circuit Design: This water tank depth level sensor adopts a modular circuit design, with military-grade multilayer PCBs, a strict material structure for the water level sensor, a reasonable layout, and accurate measurement.
4. Multifunctional: This water level sensor adopts dozens of associated special integrated circuits such as an industrial-grade microcontroller, digital temperature compensation, a super-wide voltage input, voltage stabilization, etc., with various functions.
5. Wide Application: This ultrasonic water level sensor has a wide range of applications and can be used in water and wastewater treatment, power generation, mining, and other situations requiring liquid crystal water level sensors to provide powerful assistance.

Specifications:

Item Type: Ultrasonic Water Level Sensor
Material: ABS
Operating Voltage: DC 24V
Blind Zone: 0.25-0.6m (varies by range)
Error: ±0.25%-0.5%
Display: 0.36" 4-digit, 8-segment LED
Minimum Display Resolution: 1mm
Keypad: 3 Touch Keys
Mode Output current: 4-20 mA
Electrical interface: M20X1.5 (2 sets)
Installation interface: M60
Wiring cable: Integrated terminal
Operating environment: Ambient temperature, atmospheric pressure
Proof rating: IP65
Product features: Parameter saving and restore, measuring level, liquid level, volume, weight, etc., 4-20 mA analog output, digital filtering and feedback recognition function, manually set fixed interference filtering function, supports custom mathematical function operation
Application: Water and wastewater treatment, pump rooms, collection wells, biochemical reaction tanks, sedimentation tanks, etc., electricity, Mining, slurry tanks, coal paste tanks, water treatment, etc., performance index

How to use:

Simply follow the instruction manual after removing the ultrasonic water level sensor.

Package list:

Package includes 1 x ultrasonic water level sensor

Note:

Refer to the electronic instruction manual for the correct method.
